ERV-G Yellow Band rubber expansion joint, installation underneath a road tanker

SSB 16 LV

Safety Swivel Break, for ZVA LV for AdBlue^®. Calibration switch 10 l/min – 5 l/min

Elaflon Plus PTFE 38

Filling of small containers for chemicals

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

Rail tanker unloading of petroleum based products

with FWS 80 PP St/St composite hoses and MannTek Dry Disconnect Couplings

Rail tanker toploading, TW 100 hose assemblies

ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch

Ship loading with high aromatic content fuel > 50%

UTS 150 hose assembly

MB 80 SSE

TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

ZH 50.2

High performance manual operated dispensing nozzle, for Diesel, heating oil, viscous gear and motor oils, max. flowrate 450 litres/min.

Automatic lathing machine, production of brass swivel parts

Oval flange seal FD 650-3 of ELAPAC 3 mm

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Testing

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle

Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt

Manifold for filling chemical tanktrucks

UTS hose assemblies

GasGuard LPG nozzle GG1DN

suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.

DEC – Dry Evotek Couplings:

dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling

HD-C aircraft refuelling hose

VHD 63 C NEON

Underwing aircraft refuelling

TW 100, SFC 100 TW, HD 63 C Neon

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

Polypal Clean hose assembly

Pharmaceutical production

ELAFLEX Hamburg

Delivery trucks, loading ramps

LBS 50 hose assembly for foodstuffs, FDA conform

with RMC 50 SS/SS (DIN 11851 foodstuff threaded coupling and Spannloc clamps of stainless steel)

Cargo loading of ship - various media

FWS composite hoses

PHD 100, airport depot

Hose Assemblies with Flange - Elapac seals

On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.

Oil supply system

ZV 25 manual nozzles, hose assemblies

Dantec Production hose

Composite hoses: reeling

DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75

Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose
