Construction site / on site refuelling:

ZVA 500 manual bulk nozzle (shut off by limit switch), HD hose assembly, road tanker

Hose assemblies for LPG

with flange connection, ACME connection, NPT thread

ERV-G 80.TW

ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers

Alternative fuels: DME Dimethyl Ester

DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly

Polypal Clean PCS25, RMC 25

Filling of houshold cleaning bottles

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

IBC unloading

Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.

Unloading petroleum products at the service station (road tanker to UST)

LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance

ERV VSR:

ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.

ERV-G

Ship engine room: 2 Yellow Band Expansion Joints mounted together for extra permissable movement

Adapter: MK 50-45° SS x VK 50 SS

The lever is bent to enable lever arrest (safe position when coupled)

GasGuard LPG nozzles

and LPG 16 orange hose assemblies for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane.

Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion

Picture courtesy of Macoil International, Gibraltar

Locomotive refuelling

Dispenser, ZV 32 DB nozzles with Renk coupling

ZV 500 DDC, ZVA 32 DDC, hose assembly with DDC-M coupling

Refuelling of construction site machines from the road tanker: only one hose reel, choose between two nozzles (ZV 500 for bulk, ZVA 32 automatic nozzle up to 200 l/min)

MKX 80 Ms, coupling hose assembly

Offshore FSRU (Floating Regasification Unit), connector for gasoil sludge / seawater

DDC-V 150 F

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

and Slimline dispensing hose, yellow

Rubber Expansion Joint ERV-CR 80.16

CR Expansion Joints for cold and warm water, swimming pool water, sea water, waste water (weakly sour or alkaline) also oil containing, cooling water with protective oils against corrosion, lubricating oil, grease and air, compressed air. Temperature range (depending on medium) - 25° C up to + 90° C, temporarily up to + 100° C. Electrically non-conductive.

Offshore FSRU (Floating Regasification Unit), Unloading Gasoil Sludge

TW hose assemblies, reels

Oasis BV708, 1" ball valves, isolation valves, CNG trailer loading

Airfield fixinstallation: Hose Reels JET, AVGAS

Type HD-C, aviation hose, ZVA 32

Camlock cam locking couplings:

Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)

MC 38-11/2" SS

Female hose coupling for hoses, stainless steel, with Spannloc clamps

ELAFLEX Hamburg

ERV pressure testing

PHD 63

Aircraft refuelling hose special type with non metallic plastic helix and thick wall for enhanced lateral stability. Burst pressure > 80 bar

Feel the difference: ZVA SLIMLINE 2 + ZVA SLIMLINE 2 GR

Petrol station nozzles with and without vapour recovery; premium quality from Elaflex.

Sideway storage of hose assemblies, tank truck for petrol station delivery

LG 3" hose assembly for gravity discharge, LG 2" hose assembly for vapour balance

Ship loading Naphta - STW 150 hose assemblies
