1769 images found




Production MannTek, Sweden

Production MannTek, Sweden

Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler

Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler

LPG Autogas Adapter (filler inlet) ACME

LPG Autogas Adapter (filler inlet) ACME

ACME thread 1 3/4"

V 16-1" cr

V 16-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, yellow.

Flame resistance test hose

Flame resistance test hose

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

IBC unloading

IBC unloading

Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.

MK 50 SS

MK 50 SS

TW female coupler, stainless steel

ERV-GR 80.16 ZS 2

ERV-GR 80.16 ZS 2

GREEN BAND Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

Petrol station in Mexico

Petrol station in Mexico

ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly

Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500

Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500

Bunkerboat

ZVA Slimline 2 GR, ZVA Slimline 2

ZVA Slimline 2 GR, ZVA Slimline 2

Petrol station Germany

LNG ship bunkering

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

ELAFLEX Hamburg

ELAFLEX Hamburg

Stock intake quality check – measurements

Universal hose assembly for vehicles fighting dangerous goods incidents:

Universal hose assembly for vehicles fighting dangerous goods incidents:

PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS

Hose assemblies for petroleum based procucts

Hose assemblies for petroleum based procucts

LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW

Fluorflex FXD universal hose assembly

Fluorflex FXD universal hose assembly

extremely flexible PTFE hose with maximum bending radius

GasGuard LPG nozzle GG1DN

GasGuard LPG nozzle GG1DN

suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure: 1.7 cm³.

Automatic lathing machine, production of brass swivel parts

Automatic lathing machine, production of brass swivel parts

ZVA Slimline 2, dispenser

ZVA Slimline 2, dispenser

Rubber Expansion Joint ERV-GS 80.16

Rubber Expansion Joint ERV-GS 80.16

YELLOW STEEL expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Temperature (depending on medium) range - 20° C up to + 90° C, temporarily up to + 100° C. Fire resistant (to ISO 15540) up to 30 min. and 800° C. Electrically dissipative.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Hose Reels group picture

Hose Reels group picture

Movable, pneumatic rewind system, active Vapour Recovery (VR) for gasoline fuels

GasGuard LPG nozzle GG20DN

GasGuard LPG nozzle GG20DN

With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.

ZVA Slimline 2 LA with LeverAssist hold-open aid

ZVA Slimline 2 LA with LeverAssist hold-open aid

Vehicle refuelling with LPG (L.P. Gas, Autogas)

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 EURO UL with EA 866 scuffguard, LPG 16 hose

Ship bunkering

Ship bunkering

FHD hose assembly, flange connection

ZVA_AdBlue_LV_2-Stufen-Anschlag_Step2_mod

ZVA_AdBlue_LV_2-Stufen-Anschlag_Step2_mod

Use - 2/2

UTL 50 universal hose with MannTek Dry Disconnect Coupling DDC-M 65 - 21/2" Ms

UTL 50 universal hose with MannTek Dry Disconnect Coupling DDC-M 65 - 21/2" Ms

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Oasis Engineering Ltd, New Zealand (CNG refuelling products)
