ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing nozzle seat
Oasis 'Priority Panel' with ball valves for CNG refuelling
Large hot stamping machine, production of aluminium parts
Underwing refuelling, HD-C, aircraft dispenser
TSVC 100 hose connectors
Fittings to conect two hose assemblies - available in many sizes, with Spannloc or Spannfix clamps
Hose Reel spring rewind black, FEP 50, DDC-M 50 SS
Chemical manifold
SD / Pyropal 230 saturated steam hose
FGN 2 St
Flange with male thread, steel zinc plated/chromated
VB 80 SSE
TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
Slimline 21 yellow
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
Camlock Cam Locking hose tails AMK-St 50 Ms and AVK-St 50 Ms (brass)
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
IBC
with CHS chemical hose assembly
ERV-G 80.TW
ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers
MX 80-3" SS
Female coupling for hoses, stainless steel, with Spannfix clamp
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
Rail tanker unloading of petroleum based products
with FWS 80 PP St/St composite hoses and MannTek Dry Disconnect Couplings
ELAFLEX Hamburg
Assembling Spannfix hose clamps
LPG Autogas dispenser, ZVG 2 ACME nozzle, LPG 16 dispensing hose
SG 1" 1x0 Al
Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
Slimline SF 19 black
Quality petrol pump hose for gasoline and diesel fuels. Special type 'sulphur-free'. Sulphur content of fuel does not increase, even if medium remains with the hose for a longer time, see Information 12. 15 and catalogue page 111c.
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, black.
Ship loading various media - STW 150 and UTS 150 hose assemblies
ELAFLEX quality: section view of a ERV bellows
ERV-OR "Orange Band"
ERV-G 80.TW
"Yellow Band" Rubber Expansion Joints; tank truck
Section view ERV-R Rubber Expansion Joint
Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, German)
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
