1769 images found




ZVA "LT" nozzles

ZVA "LT" nozzles

Low Temperature type -40° C for cold regions

Stainless steel hose tails - new shape

Stainless steel hose tails - new shape

Stainless steel hose tails - optimized shape for enhanced operational safety, suitable for temperatures up to 150° C. Details see Information 5.15.

SVX 50-2"

SVX 50-2"

Male hose coupling of steel with Spannfix clamps

ERV-R 80.16 SS TA

ERV-R 80.16 SS TA

Red Band Rubber Expansion Joint with "TA" PTFE lining

ZVA Slimline 2 nozzle, yellow

ZVA Slimline 2 nozzle, yellow

ELAFLEX Hamburg

ELAFLEX Hamburg

Assembling ERV large DN

DAC-M 65

DAC-M 65

MannTek Dry Aviation Coupling

Scuffguard for ZVG 2 nozzles: type EA 866

Scuffguard for ZVG 2 nozzles: type EA 866

with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black

ERV-OR

ERV-OR

"Orange Band" Rubber Expansion Joints for L.P. Gas, depot

Dispenser at the airport

Dispenser at the airport

ZVA 25 Avgas for overwing refuelling

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting

DN 2" Ms

DN 2" Ms

Double nipple brass

Petrol station in Dubai

Petrol station in Dubai

ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly

ZVA Slimline 2 GR

ZVA Slimline 2 GR

with red scuffguard; CSB 21 Coax Safety Break with BS 21 Break Sleeve; Slimline COAX hose assembly

Urea solution filling of a car:

Urea solution filling of a car:

ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)

UTS hose assembly with AMKC 32 SS and AVKC 32 SS

UTS hose assembly with AMKC 32 SS and AVKC 32 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps

Aircraft refuelling

Aircraft refuelling

Carter Underwing Nozzle, HD63C Neon, ZVF 50 JET, SC 50 Al, HD 50 C, Hose Bead BD 50

ZVA 25 for AVGAS

ZVA 25 for AVGAS

red scuffguard, AVGAS sticker; Slimline hose assembly

AN Rd 78 SS

AN Rd 78 SS

Welding nipple with foodstuff thread, stainless steel

FFBV 100, FFBV 80

FFBV 100, FFBV 80

MannTek Full Flow Ballvalves (FFBV), one way

Cabinet of road tanker:

Cabinet of road tanker:

MK 80 with VB 80 ADR SS (plug with pressure relief)

M 21-1" cr

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, blue.

Unloading LNG road tanker

Unloading LNG road tanker

DCC Dry Cryogenic Coupling

Sideway storage of hose assemblies, tank truck for petrol station delivery

Sideway storage of hose assemblies, tank truck for petrol station delivery

LG 3" hose assembly for gravity discharge, LG 2" hose assembly for vapour balance

ELAPHARM and SD Pyropal steam hose

ELAPHARM and SD Pyropal steam hose

Pharmaceutical production

UTS hose assembly

UTS hose assembly

Colour production plant

Road tanker connection hose to trailer with bend KR 50, HD 50 hose assembly MX 50-2" Ms

Road tanker connection hose to trailer with bend KR 50, HD 50 hose assembly MX 50-2" Ms

Construction of ELAFLEX composite hoses type FWS

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (German)

ERV VSD:

ERV VSD:

ERV with vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient.

ZV 500 nozzle for heating oil, hose assembly

ZV 500 nozzle for heating oil, hose assembly
