Heating oil delivery: ZH 50 nozzle, HD reel hose

MX 63-21/2" Ms

Female coupling for hoses, brass, with Spannfix clamp

DCC Dry Cryogenic Coupling for LNG

Coupling process

IBC unloading

Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.

ELAFLEX Hamburg

Narrow aisle stock fittings

Production MannTek, Sweden

Ship loading various media - STW 150 and UTS 150 hose assemblies

TGN 2" Al (TGN 50 Al)

Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.

ZV 500, hand

High performance manual operated dispensing nozzle with 'TW' coupling MK 50 for Diesel, fuel, oils, petroleum

Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS

Universal hoses with PFA coated fixed flange and Camlock fittings. Spannfix / Spannloc stainless steel clamps.

LPG Autogas Adapter (filler inlet) ACME

ACME thread 1 3/4"

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

ZVA Slimline 2 with reduced spout and Slimline hose

here: for gasoline, use in countries without vapour recovery regulation

ELAFLEX Hamburg

Aerial view over the ELAFLEX premises

ZVA Slimline 2 GR, guard 3, red, Coax hose assembly with Colour Sleeve red

Unloading petroleum products at the service station (road tanker to UST)

LG hose assembly for gravity discharge

Oasis FV103 45° Fill Valve with NC 203 P30 Nozzle, for CNG

Slimline 16 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

ZVF 50 UL for aircraft refuelling with ER 494

EA 909 green, EK 946 green

Graphic, components of a ZVA Slimline 2 GR nozzle for vapour recovery

MannTek FFBV

Full Flow Ball Valves 2-way

ZV 500 for chemials

Bulk filling of Methylene Chloride

TW coupler MK 80 SS-90° (bent lever) and dust plug VB 80 ADR SS with pressure relief

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

ZVF 50 JET overwing refuelling

with HD-C hose assembly

ERV-W 80.16

WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ELAFLEX Hamburg

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

ERV-G AF

Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.
