Media Library / Images

In order to send you the picture material you need, please click some examples – after receipt of your E-Mail we will personally contact you to hear your exact requirements.

Category

  • All
  • Products
  • Applications
  • Company

Applications

  • All
  • Petrol Station Equipment
  • AdBlue® Refilling
  • Tank Truck Equipment
  • Alternative Fuels
  • Chemicals
  • LPG / DME
  • Pharmaceuticals
  • CNG / NGV
  • Aircraft Refuelling Equipment
  • LNG
  • Rail Tankers
  • H2 Hydrogen
  • Ships & Marina
  • LH2 Hydrogen
  • Rubber Expansion Joints
  • Hose Reels

Sales Division

  • All
  • SAT
    (Hoses and Fittings)
  • EHT
    (Petrol Pump Nozzles and Accessories / Hoses)
  • ERV
    (Rubber Expansion Joints)

Sorting

  • Newest on top
  • Alphabetical

Filter by keyword



1720 images found




Unloading petroleum products at the service station (road tanker to UST)

Unloading petroleum products at the service station (road tanker to UST)

LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance

VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue

VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue

for active Vapour Recovery (VR) for gasoline fuels

KWZ x MK 80-32°

KWZ x MK 80-32°

Rail car adapter with TW coupler, bent lever

Hose Connection with TW coupling, TSG 3" Sight Glass

Hose Connection with TW coupling, TSG 3" Sight Glass

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Aircraft refuelling hoses

Aircraft refuelling hoses

VHD-C NEON, SFC TW, HD-C NEON, MC SS Al, PHD-F, VC SS Al

ZVA Slimline 2 with SG 1" Al Sight Glass

ZVA Slimline 2 with SG 1" Al Sight Glass

Oil production Kuwait

Oil production Kuwait

TW and STW hose assemblies with SFC hose flanges

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Testing

HD 100 C Neon, HD 10 sensing hose

HD 100 C Neon, HD 10 sensing hose

Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.

ZVG 2 ACME nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break

ZVG 2 ACME nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break

Slimline 16 red

Slimline 16 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Slimline 21 blue

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

ELAFLEX Hamburg

ELAFLEX Hamburg

Assembling Spannloc hose clamps

Automatic lathing machine, production of brass swivel parts

Automatic lathing machine, production of brass swivel parts

Requirements to a Hose

Requirements to a Hose

(English)

ERV with FSH:

ERV with FSH:

Flame protection cover (open)

L.P. Gas rail tanker

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

HD 100 C NEON, HD 10 C sensing hose

HD 100 C NEON, HD 10 C sensing hose

Type HD-C, aviation hose

ZVF 50 UL for aircraft refuelling with ER 494

ZVF 50 UL for aircraft refuelling with ER 494

EA 909 green, EK 946 green

MannTek DDC-V & DDC-M Dry Disconnect Couplings

MannTek DDC-V & DDC-M Dry Disconnect Couplings

CBC-PERC 100

CBC-PERC 100

Cryogenic Breakaway Coupling "PERC" for LNG after pneumatic separation

Ship loading with high aromatic content fuel > 50%

Ship loading with high aromatic content fuel > 50%

UTS 150 hose assembly

BD 63, Hose Beads at airport depot

BD 63, Hose Beads at airport depot

VK 80-2" AG Ms

VK 80-2" AG Ms

TW male coupling brass, with reduced male BSP connection (special type)

ERV-R 100.16

ERV-R 100.16

RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Ship bunkering

Ship bunkering

'Yellow Band' collapsible high

ZVF 50 JET overwing refuelling

ZVF 50 JET overwing refuelling

with HD-C hose assembly

M 21-1" NR cr

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, yellow.

LNG Refuelling

LNG Refuelling

N-LNG Nozzle, pull back handles to uncouple

ZVA Slimline 2 GRVP, Coax hose assembly

ZVA Slimline 2 GRVP, Coax hose assembly

With integrated vapour insert EK 096. For dispensers with single fi lling point or dispensers with integrated 'On / Off ' valve. The vapour return rate is regulated within the dispenser.
