SG 1½" Al
Ssight glass for ZVA 32 nozzles, e.g. for aviation refuelling.
ZVA Slimline 2 GR, black, guard 3 - side view B
ZAF Coax adapter (splitter valve) at petrol station dispenser
SPANNFIX pinned safety clamps of stainless steel
SX 75 NR SS
ELAFLEX Hamburg
Nozzle stock, ZVA Slimline 2 GR
Slimline 16 red
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer
ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
ZVG 2 K (Korea)
uncoupling from J 15 filler connection
DDC-M 100, TW hose assembly
Rail tanker bottom loading with Dry Disconnect Coupling
PSB Pump Safety Break for High Hose Dispensers
Picture shows separation of the Slimline hose assembly after a drive-off accident
ELAFLEX Hamburg, testing electrical conductivity of hose assemblies
HD-C Neon
L.P.Gas home delivery:
LPG 38 hose assembly - Aboveground storage Tank
IBC loading
Elaflon Plus FEP hose assembly
ELAFLEX Hamburg
Assembling Spannloc hose clamps
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading; detail
LTW 75 hose assembly
with MKX 75.80 Ms
ELAFLEX Hamburg
ELAFLEX stock
ERV-GR 80.16 ZS 2
GREEN BAND Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
AMK-St 38 SSE
Camlock female coupler, hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
Scuffguard for ZVG 2 nozzles: type EA 866
with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black
ZVF 50 JET overwing refuelling
LeverAssist hold-open aid for comfortable refuelling
ZV 500, hand
High performance manual operated dispensing nozzle with 'TW' coupling MK 50 for Diesel, fuel, oils, petroleum
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
ERV-G 400.10
DN 400
ELAFLEX Hamburg
Assembling VSRV bolted vacuum support ring
Camlock Cam Locking hose tails AMK-St 50 Ms and AVK-St 50 Ms (brass)
Movable Storage Hose Reel with manual rewind system white, HD 38, ZV 400
customised
FGN 2 SS
Flange with male thread, stainless steel
