M 21-1" NR cr

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, yellow.

ELAFLEX Hamburg

ELAFLEX Hamburg

Assembling dispensing hose: marking

IBC

IBC

with CHS chemical hose assembly

Slimline 16 yellow

Slimline 16 yellow

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

ELAFLEX refuelling equipment:

ELAFLEX refuelling equipment:

Quality is in the detail.

Rubber Expansion Joint ERV-R 80.16

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Unloading LNG road tanker

Unloading LNG road tanker

DCC Dry Cryogenic Coupling

Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400

Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400

for alcohol

ERV-GR ... ZS

ERV-GR ... ZS

"Green Band" Rubber Expansion Joints with limiters in chemical pumping system

ZV 19.1

ZV 19.1

ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), for diesel, fuel, petroleum and oils (also vegetable oils) up to 100 ltr./min.

L.P. Gas rail tanker

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

IBC unloading

IBC unloading

Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.

Flange hose tail stainless steel, steel flange

Flange hose tail stainless steel, steel flange

ZVA Slimline 2 nozzle with hose assembly

ZVA Slimline 2 nozzle with hose assembly

Hose Trolley HTR-T

Hose Trolley HTR-T

for terminal operations

Compact Line HD 50, Hose Reel Spring Rewind

Compact Line HD 50, Hose Reel Spring Rewind

FEP 5O, MannTek DDC-M 5O SS

Vehicle refuelling with LPG (L.P. Gas, Autogas)

Vehicle refuelling with LPG (L.P. Gas, Autogas)

GasGuard GG30 BAYO nozzle with Bayonet connector and optional splashguard, LPG 16 hose assembly, ARK 19 Safety Break

UTS hose assembly

UTS hose assembly

on board of a foodstuff road tanker

DCC Dry Cryogenic Coupling for LNG

DCC Dry Cryogenic Coupling for LNG

Coupling process

ERV-R 80.16 ZS 2

ERV-R 80.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

ELAFLEX refuelling equipment:

ELAFLEX refuelling equipment:

Quality is in the detail.

Rail tanker unloading of petroleum based products

Rail tanker unloading of petroleum based products

FWS PP St/St composite hose, MannTek Dry Disconnect Coupling, KWZ adapter

ZVA LV for AdBlue®

ZVA LV for AdBlue®

Urea solution filling of cars and light transporters

Grafik ARK 19

Grafik ARK 19

Safety Break for LPG (Autogas) dispensers. Hose Break. Reassembly after separation without tools.

RS 2 x 3 SS

RS 2 x 3 SS

Reducer Female/Male

SG 1" 1x0 Al

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Hot stamping process, TW coupling part

Hot stamping process, TW coupling part

LNG ship bunkering

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

ERV-R

ERV-R

"Red Band" Rubber Expansion Joints / ship engine room

COAX Safety Break

COAX Safety Break

CSB 21
