New narrow aisle stock (2018)

Manufacturing of turned parts

Marine bunkering and cargo hoses

offshore supply

UTS hose assembly, rail tanker top loading

ERV Rubber Expansion Joints with different flange types / flange materials

ZVG 2 DISH

Nozzle for L.P. Gas / Autogas, with 'Italian' Claw Coupling. Pictured: coupling open / closed

TWO 100

TW coupling seal for Tank truck couplings DN 100 to EN 14420-6. NBR black.

Assembling "ZS" tie rods to ERV rubber expansion joints

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

VK 80-2" AG Ms

TW male coupling brass, with reduced male BSP connection (special type)

SG 1½" Al

Ssight glass for ZVA 32 nozzles, e.g. for aviation refuelling.

DDC-K 3" SS ADR

Pressure Cap, e.g. für LPG - Special type PN 25, ADR / RID compatible. With pressure indicator and pressure relief valve.

Unloading petroleum products at the service station (road tanker to UST)

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

ELAFLEX Hamburg

Assembling Coax hoses

SG-COAX_Al

Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.

DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR

Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.

ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies

Petrol station, Indonesia

ELAFLEX Hamburg

Coax hose assembling, colours

Cargo loading / unloading of ship, STW 150, Vapour Line

Italy

Cabinet of road tanker:

MK 80 with VB 80 ADR SS (plug with pressure relief)

FWS composite hose / hose assembly

Type FWS PTFE with male threaded fitting VPH-SS

ERV-R Red Band rubber expansion joint, ship engine room

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion

SFC 50.16

hose flange; hose tail and swiveling flange of steel, Spannloc clams

ELAFLEX Hamburg

Stock intake quality check – measurements

ELAFLEX Hamburg

Assembling dispensing hose fitting

Elaflon Plus FEP 25

Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.

AN 2 SS

Welding nipple stainless steel
