Universal hose assembly UTD 19 with MC 19 SS

Cabinet of road tanker:

MK 80 with VB 80 ADR SS (plug with pressure relief)

ELAFLEX Hamburg

Hose stock, reeling up a FEP hose

Rubber Expansion Joint ERV-GR 80.16

GREEN BAND expansion joints for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.

ERV-OR

"Orange Band" Rubber Expansion Joints, road tanker

ZVA Slimline 2, ZVA Slimline 2 GR, ZVA 25

Petrol station Portugal

FGN 2 SS

Flange with male thread, stainless steel

LMD 25 Blue Band solvent hose

without helix

PHD 63

Aircraft refuelling hose special type with non metallic plastic helix and thick wall for enhanced lateral stability. Burst pressure > 80 bar

Hose assemblies

for saturated steam, chemicals, petroleum based products

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

Unloading LNG road tanker

DCC Dry Cryogenic Coupling

LNG Refuelling

LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly

Elaflex hoses

HD, TW, LPG, FXD, SL, FEP, CHS, LMS, UTS, PTFE, PCS

Simultaneous Refuelling/Filling of Diesel and AdBlue®

Picture 3

VX 50-2" NPT SS

Male hose coupling 2" NPT of stainless steel with Spannfix clamp

HD 10 C sensing hose

Universal hose UTD 38

Graphic, components of a ZVA Slimline 2 GR nozzle for vapour recovery

COAX Safety Break

CSB 21

Unloading petroleum products at the service station (road tanker to UST)

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

ZVF 50 PTL (Push-Twist-Lock), strainer inspection

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 7

Hose assemblies

for petroleum based products, chemicals, foodstuff and pharmaceuticals, LPG

Fluorline EFL 21

Universal pump hose DN 21 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue^® urea solution. Temperature range - 40° to + 100° C. Burst pressure > 64 bar.

Stainless steel Hose Reel with pneumatic rewind system, HD 50

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

VB 50 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERV-G LT 80.16

YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

Drum filling

with CHS chemical hose assembly
