TW coupling wrenches of brass or steel

EW K 50 Ms, EW K 80 Ms, EW K 100 Ms, EW K 50 St, EW K 80 St, EW TWS 50, EW TWS 80

ELAFLEX Hamburg

Assembling ERV medium DN

Unloading petroleum products at the service station (road tanker to UST)

LTW hose assembly, MK 80-32° Ms couplers with bent lever. The lever shall always be fully closed for safety reasons. For applications with limited room.

Hose Reel with manual rewind blue, TW 100, DDC-M 100 SS

Marine terminal, with grey cabinet, customised

ERV-R 80.16 ZS 2

Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

ELAPHARM Type EPH-OHM G

electrically conductive 'OHM/T', with light grey cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, black PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Oasis DMI Dispenser Manifold for CNG

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 DISH nozzle, LPG 16 hose assembly, ARK 19 Safety Break

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Unloading chemical road tanker

Tecnopal hose assembly, DDC Dry Disconnect Coupling, Guillemin adapter

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

ERV-G ... TW

Aircraft refueller

Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50

ELAFLEX Hamburg

ERV pressure testing

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

ZVA 32 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

LBS 75 hose assembly for foodstuffs, FDA conform

with VC 50 SS male coupling, Spannloc clamps

Alternative fuels: DME Dimethyl Ester

DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly

AMK 25 EASY

EASYLOC ('Camlock' stainless steel coupler to EN 14420 – 7 for male adapters AVK with captive seal) with lever arrest

Hot bitumen hose - loading (bunkering) ship

HB 100 hose assembly

Boat refuelling, ZVA 25

Latvia

Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings

Scandinavia

Oasis PM104 Priority Panel / Manifold, for CNG

MK 100-90° SS

Special type with bent lever

Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral

VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571

IBC unloading

Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

SG-COAX

Sight Glass for ZVA Slimline 2 GR

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting

ZV 400

High performance manual operated dispensing nozzle. Special type with stainless steel swivel DG 40 SS
