ELAFLEX Hamburg
ERV pressure testing
Hose Connection with TW coupling, TSG 3" Sight Glass
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ERV-G ... TW
Aircraft refueller
CBC-PERC 100
Cryogenic Breakaway Coupling "PERC" for LNG after pneumatic separation
Safety Swivel Break
SSB 16.0
MannTek Safety Breakaway Coupling SBC 80 SS F
with flange connection
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
MK 50 SSE
TW female coupler. Material: stainless steel with universally resistant PFA coating (red)
ZAF Coax adapter (splitter valve) at petrol station dispenser
ERV-G 100.16
YELLOW BAND Rubber Expansion Joint suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.
DAC-V 65, DAC-M 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action
PHD 100, airport depot
ERV VSR:
ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.
ZV 400
High performance manual operated dispensing nozzle. Special type with stainless steel swivel DG 40 SS
Universal hose assembly UTS 50 with VC 50 SS / SS
Customer protected special design ZVA Slimline 2 nozzle
IBC unloading
Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.
Underwing refuelling, HD-C, aircraft dispenser
ZVG 2 DISH nozzle for L.P. Gas / Autogas, LPG 16 hose assembly
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Automatic rod turning machines
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
Anti-Kinking Spiral 'KSS'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the new Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
Chains K 160, K 160 SS, K 180 L, K 200, K 200 SS, K 260 L, K 300, K 300 SS, K 360, K 360 SS
Connection between coupling and dust cap / plug
ELAFLEX Hamburg
ERV inner protection sleeve/tube "SR"
DDC-S 2 1/2" PE
Dust plug for DDC-M 65 Dry Disconnect Coupling
Elaflex hose assemblies
Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings
AN 2 SS
Welding nipple stainless steel
Adapters / couplers for vehicles fighting dangerous goods incidents:
Plugs and Caps MB 50 SS/Vi, VB 50 SS, VB 100 SS, BK 2" SS/Vi, BK 3" SS/Vi
