HD-C LT, Low Temperature

Antarctica: Low Temperature aircraft refuelling hoses in action; fuel transfer from drums via mobile pump

SD / Pyropal 230 saturated steam hose

VB 100 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

SPANNFIX pinned safety clamps of aluminium

SX 75 Al

Flexible bronze pipe connector BWO

Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps

Elaflon Plus FEP 25

Universal hose ELAFLON PLUS FEP with seamless FEP lining, resistant to all commonly used chemicals, see resistance chart. Suitable for both suction and delivery (Type FEP D = delivery only). W.P. up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° C up to + 100° C, briefly up to 130° C. Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min (open system). Meets EN 12115.

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapters Flange FGN 2" SS x VK 50 SS/Vi, FGN 3" SS x VK 50 SS/Vi, FGN 4" SS x VK 50 SS/Vi

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

Hose assemblies for LPG

DN 25, DN 32, DN 50 / with flange connection, ACME connection, NPT thread

ZVA 25 GR

For the filling of small containers and IBC with solvents. With vapour recovery.

Elaflex hoses

PTFE, FEP, HD, UTS

Composite hose Danoil 7GG, DDC-M Dry Disconnect Coupling, airport depot

ERV-G 1000, ERV-BR 300

Oasis CNG refuelling equipment:

Ultra Fast Fill System (Diagram, German)

VK 80-2" AG Ms

TW male coupling brass, with reduced male BSP connection (special type)

ELAFLEX Hamburg, testing electrical conductivity of hose assemblies

HD-C Neon

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

Hose Assemblies with Flange - Elapac seals

On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Machining spouts

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

EA 866 scuffguard orange with ZVG 2 ACME nozzle

The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space

ZVF 50 PTL (Push-Twist-Lock), strainer inspection

Fuel grade identification for ZVA to standard

Attach with EK 145 Product Badge

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Hose assembly for L.P. Gas

LPG 50, DGC-M 50

Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®

old design

EASYLOC Cam Locking Coupling

easy deactivation of lever arrest

ELAFLEX Hamburg

Incoming goods / flanges
