Offshore FSRU (Floating Regasification Unit), Unloading Gasoil Sludge
TW hose assemblies, reels
Manufacturing of turned parts
NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)
Nozzle boot f. ZVF 50 with additional spout retainer
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
ELAFLEX Hamburg
ELAFLEX stock
KR 50
bend with VK 50 x MK 50, 60°
Double Closing COAX Safety Break
CSB 21 DC
Oasis DMI Dispenser Manifold for CNG
SG 1½" Al
Ssight glass for ZVA 32 nozzles, e.g. for aviation refuelling.
Polypal Clean hose assembly
Pharmaceutical production
Production MannTek, Sweden
DG 50 Al - new Aluminium swivel for ZVF 50
Section view
For long and heavy aviation refuelling hoses: Hose Beads 'BD' to EI 1522 standard
They notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
Fluorflex FXD universal hose assemblies with anti kinking spiral KSS
extremely flexible PTFE hose with maximum bending radius and safety against kinking
LPG ship-to-ship cargo transfer
Danchem PASS composite hose
PHD 63
Aircraft refuelling hose special type with non metallic plastic helix and thick wall for enhanced lateral stability. Burst pressure > 80 bar
Rubber Expansion Joint ERV-GR 80.16
GREEN BAND expansion joints for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.
Unloading petroleum products at the service station (road tanker to UST)
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
GasGuard LPG nozzles: optional Magnet in the guard
For contactless activation of dispensers with reed switch technology
SG1" 1x0 Al, EA075.1, EA375.0AF, DG 50.1 Al, DG 50.2 Al
Storz Safety Coupling SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
Elaflon Plus FEP hose assembly, FFC-SS fixed hose flange
ELAFLEX refuelling equipment:
Quality is in the detail.
ERV-GR Green Band rubber expansion joint, Biogas entergy plant
ERV-G
Pump-tank connection; lateral offset
ELAFLEX Hamburg
Stock special flanges, pick by voice, scanning
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Solvent filling with integrated vapour recovery in the nozzle
ZVA 25 GR, UTS hose assemblies
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle, HD hose assembly, road tanker
