M 63 2½" SS, VD 76/63 PU

Hose coupling with female thread

Double Closing Safety Swivel Break

SSB 16 DC

Elaflex hose assemblies

Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings

UTS hose assembly with AMKC 32 SS and AVKC 32 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps

ERV-G 80.TW

"Yellow Band" Rubber Expansion Joints; tank truck

Slimline 16 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

SMS 19-3/4"

Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.

CHD 25

Lilac Band chemical hose without helix, DN 25

ZVF 50 JET overwing refuelling

with HD-C hose assembly

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapters Flange FGN 2" SS x VK 50 SS/Vi, FGN 3" SS x VK 50 SS/Vi, FGN 4" SS x VK 50 SS/Vi

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting

IBC unloading

Female hose coupling MC 38-S60 SS (with Spannfix clamps) and LMS solvent hose. Direct connection of a hose assembly to the IBC.

DG 50 Al - new Aluminium swivel for ZVF 50

Section view

Road tanker connection - MK 50 Ms, VB 50 Ms, Chain

Anti theft protection with padlock

Manufacturing warm forged parts

Example SC 150 Spannloc clamp

Tar (bitumen) spraying hose HB-ST in action

HD-C LT, Low Temperature

LT (Low Temperature) types of our aircraft refuelling hoses are suitable for use in especially cold regions - high flexibility.

Elapharm

Hose Assemblies for use in the Pharmaceutical and Biotech Industries

Pipe with AVKI 50 SS, hose assembly with AVKX 50 SS, lever movement

'Camlock' stainless steel female and male coupling to EN 14420 - 7

VB 50 SS

TW dust plug, stainless steel

ZVA Slimline 2 LA with LeverAssist hold-open aid

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

Wear Advice

VHD 50

ElaSil® Silicone hose assemblies DN 13-102

For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection

Unloading petroleum products at the service station (road tanker to UST)

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

ERV-G 100.16

YELLOW BAND Rubber Expansion Joint suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ZVA Slimline 2, black, guard 3 - side view

Hose Reel with hydraulic rewind system blue, TW 100, DDC-M 100

UTS hose assembly with AMKC 25 SS/SS

'Camlock' stainless steel coupler to EN 14420 - 7 with hose tail and Spannloc stainless steel clamps
