HD 100 C NEON, HD 10 C sensing hose

Type HD-C, aviation hose

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.

ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies

Maroc

VB 50 SS

TW dust plug, stainless steel

ERV-CR

"CR" Rubber Expansion Joints - ballast water treatment skid

ELAFLEX Hamburg

Delivery trucks, loading ramps

Unloading: MK couplers with DDC-V 80 adapter

KWZ x MK 80-32°

Rail car adapter with TW coupler, bent lever

ZVA Slimline 2 nozzles with splashguard, Slimline hose assemblies

Refuelling at a petrol station in the United Arab Emirates

Type PCS, Polypal Clean

PCS 25, PCS 63, PCS 100

Connection aircraft refueller to flanged hose assembly

ERV-G 100 TW, HD 100 C, TW-flange

Road tanker reel with HD 50 hose assembly, ZV 500 nozzle

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting ZVA

Hose Assemblies with Flange - Elapac seals

On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.

ERV TA:

ERV with white PTFE lining. Used when the chemical resistance of the chosen ERV type is insufficient. Resistant to all commonly used liquids. Electrically isolating, therefore not suitable for flammable liquids in Ex-Zones. Admissible working temperature of expansion joint has to be observed. For maximum pressure of 6 bar – not suitable for vacuum.

BK 3 Ms

Cap with 3" female BSP thread, brass

Flange hose tail stainless steel, steel flange

Storz Safety Couplings Type SHK

upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.

MK-A 80 SS, TW female coupler with Active Safeguard Lever, VB 80 SS

Pull slider to unlock

Swivels DG 25 SS, DG 38 SS, DG 50 SS with hose assembly

Swivels serve to avoid hose torsion (increase of life span) and help for easier handling

ERV VSRV:

ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.

Rubber Expansion Joint ROTEX 80.16

ROTEX expansion joints suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative.

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

FF-St 80 SSE

Fixed flange hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)

ERV-R

"Red Band" Rubber Expansion Joints with limiters / pump station

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

ZVA Slimline 2 and ZVA Slimline 2 GR, special colour light green

Elapharm EPH-OHM with welding end

Hot bitumen hose - loading (bunkering) ship

HB 100 hose assembly

ZVA Slimline 2 LA with LeverAssist hold-open aid
