ERV SR:

ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.

Transport protection for threaded fittings

Aircraft refuelling: MannTek sampling unit in hydrant system

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components – detail view

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

V 19-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 19 SF (sulphur free) hose, black.

Hot stamping process, production TW coupling parts

ELAFLEX Hamburg

Manufacturing bronze corrugated pipes

Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium

HD 50 C, VC 50 SS, SC 50 Al

Production MannTek, Sweden

ERV-R 100.16

RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

ELAFLEX Hamburg, marking tested hose assemblies

Polypal Clean, MX 50 SS

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

Drum unloading chemical industry

UTS hose assemblies with Easyloc cam locking couplings

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter for Rail Tanker 51/2" connection KWZ SS/Vi x VK 50 SS/Vi

Lube oil plant: manifold with DDC-V Dry Disconnect Couplings

Oasis FV103 Fill Valve, CNG service station

Elaflex hose assemblies and Rubber Expansion Joints for petroleum based products

HD 100 C NEON, HD 10 C sensing hose

Type HD-C, aviation hose

LPG 16 dispensing hoses for L.P. Gas (Autogas)

black or orange

Oasis TH Tank Head Valves, CNG trailer

ELAFLEX refuelling equipment:

Quality is in the detail.

EL 800 Earthing Strap with vulcanized copper strand

Electrically conductive bonding. Use for road tankers for petroleum based products, solvents, bulk tankers, forklifts, cable cars and cable Electro-Buses.

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

MK 80-2" IG

TW female coupler, brass, with reduced female thread (special type)

Aljac Closed Circuit Sampler (CCS)

Hydrant-dispenser

Oasis FV103 Fill Valve, CNG dispenser

Oasis 'Priority Panel' with ball valves for CNG refuelling

ERV VSRV:

ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.

Slimline 19 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
