ZVG 2 EURO

(Push-In-Coupling) to EN 13760. One-handed operation possible.

MC 38-11/2" Ms

Female hose coupling for hoses, brass, with Spannloc clamps

Simultaneous Refuelling/Filling of Diesel and AdBlue®

Picture 2

L.P.Gas unloading of road tanker

LPG 50 hose assembly

Ferrule threaded hose coupling M 19-1" cr

for petrol station dispensing hoses

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

ELAFLEX Hamburg

Nozzle stock, ZVA Slimline 2 GR

Unloading LNG road tanker

DCC Dry Cryogenic Coupling

MannTek Dry Disconnect Couplings:

DDC-M 80-3" SS with PolypalClean hose assembly, DDC-V 80-3" SS with pipe end

Slimline hose assembly, section view

ERV VSRV:

ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.

Oasis NGV / CNG Refuelling Equipment

Elaflon Plus FEP hose assembly, crimped foodstuff fitting

ELAFLEX Hamburg, narrow aisle stock for small parts

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

LNG Refuelling

N-LNG Nozzle, push handles to couple

ELAFLEX Hamburg

Aerial view (left to right): Technical dept., small aisle stock, stock with loading ramps

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (German)

Rubber Expansion Joint ERV-GS HNBR 80.16

YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.

Coax hose assembly, section view

Quality in the detail: valve assembly of a ZVA Slimline 2 petrol station nozzle

LNG Refuelling

LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly with cover hose, bonding cable

UTL 50 universal chemical hose assembly with KSS anti-kinking-spiral

and DDC Dry Disconnect Coupling

KSS-SD of stainless steel

for saturated steam hoses. These hose assemblies are subject to high wear. The main stress area for hose assemblies is also at the joint end is protected.

Pipe with AVKI 50 SS, hose assembly with AVKX 50 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7

Alternative fuels: HVO (hydrotreated vegetable oil) and E 85 (gasoline with up to 85% ethanol)

ZVA Slimline 2, ZVA Slimline 2 GR

Rose Reel spring rewind white, HD 38 C, ZVF 50

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Plettenberg factory 1

Rubber Expansion Joint ERV-CR 80.16

CR Expansion Joints for cold and warm water, swimming pool water, sea water, waste water (weakly sour or alkaline) also oil containing, cooling water with protective oils against corrosion, lubricating oil, grease and air, compressed air. Temperature range (depending on medium) - 25° C up to + 90° C, temporarily up to + 100° C. Electrically non-conductive.
