IBC loading
Elaflon Plus FEP hose assembly
ELAFLEX Hamburg
Forklift loading station
Unloading petroleum products at the service station (road tanker to UST)
MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Nozzle boot NB-ZVF 50
for ZVF 50 Oberflügel-Zapfventile
Hose assemblies for petroleum based products
Yellow Band quality with nozzle, TW coupling, flange connection
ERV-R 80.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
Road tanker hose reel, made by Elaflex Italia
with LPG hose assembly
VK 80 - 2" IG Ms
TW male coupling brass, with reduced female BSP connection, one piece adapter (special type)
Manifold at petroleum storage terminal
STW 150 hose assemblies, SFC 150.16 hose flanges
Hose Reel Spring Rewind
HD 25 C, ZVA 25 AF red, GKG 25, EKG 1200
H2 Hydrogen
H2 25 D Hydrogen hose, SFC 25, MX 25, VC 25
oasis TH104 Tank Head Valves, CNG trailer
SG 1" - SSB 16 Propeller
Sight Glass with SSB 16 Safety Break. Compact and lightweight combination of the functions hose swivel, Safety Break and Sight Glass (with propeller).
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
Hoses for Liquefied Petroleum Gas / Autogas
LPG 13, LPG 16 black/orange, LPG 19
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
LNG Refuelling
Align N-LNG Nozzle
ELAFLEX Hamburg
Commissioning / Pick by Voice
ELAFLEX Hamburg
ERV pressure testing
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
ZVA-RG
Automatic nozzle ZVA DN 19, of red bronze (gunmetal), for solvents and corrosive media. Flowrate up to 60 l / min.
ELAFLEX quality: section view of a ERV bellows
ERV-OR "Orange Band"
ZVF 50 JET
ZVA Slimline 2, dispenser
Estonia
Oasis IV 108 Inline Trailer Breakaway, for CNG
ELAPHARM Type EPH 25
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Terminal loadingarm
'SBC-C'
ContiTech Production ERV
In production testing, rubberized fabric
ELAFLEX Hamburg
ERV assembling
HD-C LT, Low Temperature
LT (Low Temperature) types of our aircraft refuelling hoses are suitable for use in especially cold regions - high flexibility.
