1769 images found




Camlock cam locking couplings

Camlock cam locking couplings

top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version

Fluorflex FXD 50

Fluorflex FXD 50

PTFE / EPDM Universal helical hose - high performance chemical hose to DIN 26054, combining the universal chemical resistance of PTFE with exceptional flexibility and tight bending radius.

ZVA Slimline 2, ZVA Slimline 2 GR (Special type with PowerPerformer)

ZVA Slimline 2, ZVA Slimline 2 GR (Special type with PowerPerformer)

ZVA Slimline 2

ZVA Slimline 2

with Sight Glass

ERV-G 80.TW

ERV-G 80.TW

Yellow Band rubber expansion joint with TW flanges

Urea solution filling of a car:

Urea solution filling of a car:

ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)

Ship bunkering

Ship bunkering

'Yellow Band' collapsible high

M 21-1" cr

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, green.

Vehicle refuelling with LPG (L.P. Gas, Autogas)

Vehicle refuelling with LPG (L.P. Gas, Autogas)

GasGuard GG30 BAYO nozzle with Bayonet connector and optional splashguard

Adapter / Safety Breakaway Coupling for rail tanker loading / unloading

Adapter / Safety Breakaway Coupling for rail tanker loading / unloading

SBC 100 Safety Breakaway Coupling with RV-KW 51/2", RV-VK 80

DN 1" SS

DN 1" SS

Double nipple stainless steel

ZVA Slimline 2 GR nozzle

ZVA Slimline 2 GR nozzle

with Coax hose assembly (one side open end, inner vapour hose visible)

Unloading chemical road tanker

Unloading chemical road tanker

Elaflon PTFE hose assembly, TW couplings

Compact Line HD 50, Hose Reel Spring Rewind

Compact Line HD 50, Hose Reel Spring Rewind

FEP 5O, MannTek DDC-M 5O SS

ContiTech Production hose

ContiTech Production hose

Dispensing hose, after mandrel removal, before coiling

PHD-F aircraft refuelling hose

PHD-F aircraft refuelling hose

PHD 63 F

Construction site / on site refuelling:

Construction site / on site refuelling:

ZVA 500 manual bulk nozzle

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

ERV-G AF

ERV-G AF

Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.

MannTek DGC DryGasCouplings for L.P. Gas

MannTek DGC DryGasCouplings for L.P. Gas

DGC-M 80-3", DGC-V 80-3" with DDC-K dust cap

M 21-1" NR cr

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.

GasGuard LPG nozzles

GasGuard LPG nozzles

and LPG 16 orange hose assemblies for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane.

KR 50

KR 50

bend with VK 50 x MK 50, 60°, with VB 50 P dust plug

LBS 75 hose assembly for foodstuffs, FDA conform

LBS 75 hose assembly for foodstuffs, FDA conform

with VC 50 SS male coupling, Spannloc clamps

Hosebun® hose saddle 'HSB'

Hosebun® hose saddle 'HSB'

provides for a professional and material-protecting suspension of hose assemblies

Tank container filling coupling: MK 80-32 SS with VB 80 SS

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS

Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS

Universal hoses with PFA coated fixed flange and Camlock fittings. Spannfix / Spannloc stainless steel clamps.

Hose assemblies

Hose assemblies

for petroleum based products, chemicals, foodstuff and pharmaceuticals, LPG

ZVA Slimline 2, Sight Glass SG 1" Al, hose assembly

ZVA Slimline 2, Sight Glass SG 1" Al, hose assembly

Fire-resistant cover for hoses

Fire-resistant cover for hoses
