Group picture
TW 100, DDC-M100 4", Hose Reel VR Spring Rewind System, ZVA Slimline 2 GR, ERV-G 1000, ERV-BR 300
ELAFLEX Hamburg
Forklift loading station
Cabinet of road tanker:
MK 80 with VB 80 ADR SS (plug with pressure relief)
ZVA Slimline 2, ZVA Slimline 2 GR, ZVA 25
Petrol station Portugal
ZVA Slimline 2, filler inlet, Diesel refuelling
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 DISH nozzle, LPG 16 hose assembly, ARK 19 Safety Break
Rail tanker unloading of petroleum based products
Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses
Solvapal hose assemblies
Solvents
VB 100 ADR Al with pressure relief
Plug for MK 100
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
ERV-G 100 TW
Aircraft refueller
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Solvent filling with integrated vapour recovery in the nozzle
ZVA 25 GR, UTS hose assemblies
KR 50 - 21/2", HD reel hose
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
ELAFLEX Hamburg
Hose assemblies, marking after testing on the fitting
Slimline 21 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
Hose assemblies for LPG
with flange connection, ACME connection, NPT thread
Large hot stamping machine, production of aluminium parts
Mobile tank for solvents
hose assembly UTS 50 with MKX 50 SS and VB 50 SS
GasGuard nozzle GG 1 DN, hose assembly, nozzle boot NB-GG
Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400
for alcohol
Oasis 'Priority Panel' with ball valves for CNG refuelling plants
GasGuard LPG / Autogas refuelling equipment
Nozzles, nozzle boot for dispenser installation, LPG 16 hose assemblies, Safety Break ARK 19
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 18
Aircraft refuelling
Carter Underwing Nozzle, HD 63 C Neon, ZVF 50 AVGAS, SC 50 Al, HD 50 C, Hose Bead BD 50
Scuffguard for ZVG 2 nozzles: type EA 866
with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black
RM-St 50 SSE
Female foodstuff threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
ELAFLEX Hamburg
Main building / entrance
ERV-BR 300
for abrasive Media
HD 100 C Neon, underwing refuelling
Aircraft Dispenser
ERV SR:
ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.
