Elaflex hose assemblies
Hose fittings: threaded, flanged, quick couplings, Dry Disconnect Couplings
UTL 50 universal hose with MannTek Dry Disconnect Coupling
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters TW to EN 24420-6 MK 50 SS/Vi x MK 50 SS/Vi, VK 80 SS/Vi x VK 50 SS/Vi, VK 50 SS/Vi x VK 50 SS/Vi, MK 80 SS/Vi x VK 50 SS/Vi
NB-ZVF 50 SR, ER 583 PTL
Nozzle boot f. ZVF 50 with additional spout retainer
Slimline quality dispensing hose for the forecourt
Production TW couplings
TGN 2" Al (TGN 50 Al)
Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.
ERV-CR ... ZS
"CR" Rubber Expansion Joints; water purification plant
ELAFLEX Hamburg
Mini Installation instructions, on request
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
UTD hose assemblies in Ex-zone
Universal hose assembly for vehicles fighting dangerous goods incidents:
PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS
Oasis 'Priority Panel' with ball valves for CNG bus refuelling
Saturated steam hose fitting SMS 19-3/4" SS/SS
completely of stainless steel, with self-securing bolts and nuts; possibility to attach stainless steel anti-kinking spirals KSS-SD
SPANNLOC bolted safety clamps of stainless steel
SC 75 SS
Aircraft refuelling hoses
VHD-C NEON, SFC TW, HD-C NEON, MC SS Al, PHD-F, VC SS Al
Oasis FV103 90° Fill Valve with Bus & Truck Nozzle, for CNG
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
Maintenance at the petrol station
ERV-OR ... ZS
"Orange Band" Rubber Expansion Joints with limiters; heating plant
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
ELAFLEX Hamburg
Assembling dispensing hose
GasGuard LPG nozzle GG30:
with Splashguard
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
Lube oil filling, ZV 19 manual nozzle
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
M 16-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, blue.
