Rail tanker loading and unloading of petroleum based products
ZVA Slimline 2 and ZVA Slimline 2 GR
Dispenser, Czech Republic
Overwing refuelling ZVA 25
HD-C hose assembly
TSVX 50
Hose connectors with double shank of hot stamped brass, with Spannfix safety clamps of hot stamped aluminium.
HB hot bitumen hose - loading plant
Oasis EC100 electrically isolating couplers for CNG
Nozzle boot NB-GG
for GasGuard LPG nozzles
TSVC 100 hose connectors
Fittings to conect two hose assemblies - available in many sizes, with Spannloc or Spannfix clamps
ELAFLEX hose quality: braided reinforcements
serve for flexibility, low weight and increased lifetime
Ship bunkering
FHD hose assembly, flange connection
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Assembling hall, meterial logistics
Offshore oilrig: TW hose assemblies, DDC Dry Disconnect Couplings
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
FGN 2 St
Flange with male thread, steel zinc plated/chromated
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
Nozzles with SIGHT GLASS
ZVA Slimline 2 with SG 1" Al, ZVA Slimline 2 GR with SG-COAX
Elaflon PTFE 25
ERV TAS:
ERV with PTFE lining and PTFE vacuum support ring. Properties like type TA, but also suitable for vacuum service, up to 70° C.
Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium
HD 50 C, VC 50 SS, SC 50 Al
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
and Slimline dispensing hose, black
MannTek Dry Disconnect Couplings:
DDC-V 50-2", DDC-V 50 F, DDC-M 50-2", DDC-M 80-3"
Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
Urea solution filling for light vehicles – parallel to Diesel refuelling
ZVA LV for AdBlue® / ZVA Slimline 2
ERV-W 80.16
WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.
DDC-K 3" SS ADR
Pressure Cap, e.g. für LPG - Special type PN 25, ADR / RID compatible. With pressure indicator and pressure relief valve.
DAC-V 65, DAC-M 65
Coupling test facility
HD-C LT, Low Temperature
Antarctica: Low Temperature aircraft refuelling hoses in action
Universal hoses UTL with DDC Dry Disconnect Couplings
ELAFLEX refuelling equipment:
Quality is in the detail.
ZVA Slimline 2 / ZVA Slimline 2 GR
Petrol station nozzles with (top) and without vapour recovery (below)
