Integrated Diesel Drip Catcher for ZVA Slimline 2

ERV-R 100.16

RED BAND Rubber Expansion Joint for water, drinking water (DVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature range - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Adapters / couplers for vehicles fighting dangerous goods incidents:

Adapter Sight Glass SG 2" SS/Vi with MK 50 SS/Vi and VK 50 SS/Vi

Scuffguard for ZVG 2 nozzles: type EA 866

with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black

ELAFLEX Hamburg

ELAFLEX stock

L.P. Gas road tanker: long hose reel, LPG 32 and LPG 25 hose assemblies

SBC-C 150.16

MannTek Safety Breakaway Coupling with cable release, PN 16 flange connection

Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY

EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp

Rubber Expansion Joint ROTEX 80.16

ROTEX expansion joints suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative.

Unloading: MK couplers with DDC-V 80 adapter

Oasis FV103 180° Fill Valve with Bus & Truck Nozzle, for CNG

Boat refuelling, Hose Reel, ZVA Slimline 2

MannTek Dry Gas Couplings, Safety Breakaway Couplings and swivels for LPG

Elaflon Plus FEP 25

SPANNLOC bolted safety clamps of aluminium

SC 75 Al

ZVF 50 JET for aircraft refuelling

with EA 951 PTL black, SC 50 Al, HD 50 C and BD 50

ZVA Slimline 2 GR nozzles

KW bronze corrugated pipe with cathodic protection

Cathodic protection flexible pipe connector (bronze corrugated pipe) for electrically insulating, cathodically protected installations. Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps - and directly underneath the dispensers

V 16-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, red.

Offset UST filling point, LTW hose assemblies with TW couplings

Operator

Elapharm clamp fittings

Nozzles and hose assemblies for the forecourt

ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies

ERV-BR 300

for abrasive Media

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

ZV 500 for chemials

Bulk filling of Methylene Chloride

VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue

for active Vapour Recovery (VR) for gasoline fuels

Slimline 16 green

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

LNG Refuelling

LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable

Maintenance at the petrol station

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar
