TSVC 100 hose connectors
Fittings to conect two hose assemblies - available in many sizes, with Spannloc or Spannfix clamps
L.P.Gas unloading of road tanker
LPG 50 hose assembly
ZVA_AdBlue_LV_2-Stufen-Anschlag_Step1
Use - 1/2
Hose Assemblies with Flange - Elapac seals
Flange seal: Elapac.
Hose Assemblies with Flange - Elapac seals
On board of an aircraft refueller: TW-hose, Spannloc flanged coupling; flange seal: Elapac.
ELAFLEX Hamburg
Unloading petroleum products at the service station (road tanker to UST)
LTW hose assembly, MK 80-32° Ms couplers with bent lever. The lever shall always be fully closed for safety reasons. For applications with limited room.
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps). Direct connection of a hose assembly to the IBC.
M 16-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, black.
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, vent hose assenbly with 'VC-LNG'
Tank storage: manifold with DDC Dry Disconnect Couplings, TW hose assemblies
ELAFLEX refuelling equipment:
Quality is in the detail.
NB-ZVF 50
Noozle Boots for ZVF 50 Overwing Nozzles
ERV with FSH:
Flame protection cover (closed)
ERV-CR
"CR" Rubber Expansion Joints - ballast water treatment skid
HB 19 ST tar spraying hose
Hot stamping process, production TW coupling parts
ZVA Slimline 2
RS 21/2 x3 SS
Reducer Female/Male
Drum unloading chemical industry
UTS hose assemblies with Easyloc cam locking couplings
Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium
HD 50 C, VC 50 SS, SC 50 Al
MannTek DDC-V & DDC-M Dry Disconnect Couplings
Dantec Production hose
Composite hoses: hose with customer braning, application of outer helix
Elaflon PTFE
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Production plastic precision parts
Slimline hose assembly, section view
PSB Pump Safety Break for High Hose Dispensers
ERV-R
"Red Band" Rubber Expansion Joints; wastewater pump
ZVA Slimline 2 GR with splashguard, hand
scuffguard and Splashguard green, Slimline hose assembly with Colour Sleeve green
