Media Library / Images

Offshore Methane gas production

UTS / CHS hose assemblies

ZVA Slimline 2, black, guard 3 - side view

Locomotive refuelling

Dispenser, ZV 32 DB nozzles with Renk coupling

ZVG 2 DISH

Nozzle for L.P. Gas / Autogas, with 'Italian' Claw Coupling. Pictured: coupling open / closed

Hose Connection with TW coupling, TSG 3" Sight Glass

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Ship sided connectors for bunkeringof fuel, lube oils, fresh water; unloading of sewage

DDC Dry Disconnect Couplings with caps

Safety Swivel Break SSB 16 SS of stainless steel f. ZVA HV for AdBlue®

new design

Rose Reel spring rewind white, HD 38 C, ZVF 50

ELAFLEX Hamburg

Aerial view over the ELAFLEX premises

ELAFLEX refuelling equipment:

Quality is in the detail.

ERV-G 400.10

DN 400

MKC 75.80 SS

TW female two-part coupler, stainless steel

Oasis FV103 45° Fill Valve with NC 203 P30 Nozzle, for CNG

Rail tanker loading L.P. Gas

DGC Dry Gas Couplings, SBC Safety Breakaway Couplings

Elaflon Plus FEP hose assembly, crimped foodstuff fitting

ZV 19.1

ZV 19 manually operated dispensing nozzle, DN 19 (3/4"), for diesel, fuel, petroleum and oils (also vegetable oils) up to 100 ltr./min.

Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY

EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.

Bonding Reel grey, high visibility bonding cable

RVX 32-11/4 SS

Hose coupling with male foodstuff thread and Spannfix clamps

Type PCS, Polypal Clean

PCS 25, PCS 63, PCS 100

SG-COAX_Al

Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.

ZVG 2 K (Korea)

uncoupling from J 15 filler connection

Hose assemblies

with flanged coupling, Dry Disconnect Coupling, TW coupling

DCC Dry Cryogenic Coupling for LNG

Coupling process

ZH 50 nozzle with MK50SS + HD hose assembly, DDC-V 80 Ms with cap, MK 80 Ms with VB 80 P

Construction site / on site refuelling:

ZVA 500 manual bulk nozzle

GasGuard GG11R

The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.

Hose assemblies for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

ZVA Slimline 2 nozzle with hose assembly
