Unloading: MK couplers with DDC-V 80 adapter
Loading Brine (salt solutíon for winter service): CHS hose asssembly, DDC Dry Disconnect Coupling
AMK 25 EASY
EASYLOC ('Camlock' stainless steel coupler to EN 14420 – 7 for male adapters AVK with captive seal) with lever arrest
UTS 200 hose assembly in chemical plant
Italy
Railtanker
MannTek DDC-V 80 F Dry Disconnect Couplings (tank unit with flange), Pressure Caps PN 25 with pressure relief
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle, HD hose assembly, road tanker
Underwing refuelling, HD-C hose assembly
BD 63 Hose Beads
to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
Road tanker Sweden
large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)
Oasis 'Priority Panel' with ball valves for CNG refuelling
SL 16 for AdBlue® (blue) hose assembly with anti-kinking sleeve, colour sleeve
ZVA Slimline 2 GR, CSB 21, SL 21 Coax
petrol station Dubai - Vapour Recovery
oasis TH Tank Head Valves, CNG trailer
Aircraft refuelling: MannTek sampling unit in hydrant system
SPANNFIX pinned Sicherheits Klemmbacken aus stainless steel
SX 75 SS
ERV Rubber Expansion Joints
Picture 3
DAC-V 65
MannTek Dry Aviation Coupling
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps) and LMS solvent hose. Direct connection of a hose assembly to the IBC.
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading; detail
ERV ZS from DN 250 (PN 16)/350 (PN 10):
Tied Flanges – Type ZS, Tie rods with outer limitation in spherical discs and conical seats
Hose assemblies
for petroleum based products, chemicals, foodstuff and pharmaceuticals, LPG
Hose Assemblies with Flange - Elapac seals
Flange seal: Elapac.
Hose assembly TW 75 with MKX 75.80 Ms
TW hose with TW female coupler, two piece
M-St 50 SSE
Female threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
ZVA Slimline 2 / ZVA Slimline 2 GR
Rail tanker unloading of petroleum based products
LTW hose assemblies, TW couplings
SSB 16 Safety Break: Abriss
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Filling of Heating Oil Tanks: Adapter KR 50-21/2"
for difficult to reach filler inlets
Swivel EA 075 A f. ZVA HV for AdBlue®
old design
