Media Library / Images

Unloading chemical road tanker

UTS hose assembly

ZVG 2 EURO UL nozzle for L.P. Gas / Autogas

with EA 866 scuffguard black and LPG 16 S hose assembly black

ZVF 50 JET for aircraft refuelling

with EA 951 PTL black, SC 50 Al, HD 50 C and BD 50

ELAFLEX Hamburg, marking tested hose assemblies

Polypal Clean, MX 50 SS

LTW 100 hose assembly

with MC 100-51/2" Al

RS 21/2 x3 SS

Reducer Female/Male

Elaflex LTW hose assembly, Matterhorn

Supply of the mountain top station via IBC unloading

Rubber Expansion Joint ERV-GS 80.16

YELLOW STEEL expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Temperature (depending on medium) range - 20° C up to + 90° C, temporarily up to + 100° C. Fire resistant (to ISO 15540) up to 30 min. and 800° C. Electrically dissipative.

ERV ZS:

Tied Flanges – Type ZS, Tie rods with outer limitation in rubber bushings

VR Hose Reel Spring Rewind red, ZVA Slimline 2 GR green, ZAF 2

for active Vapour Recovery (VR) for gasoline fuels

Offset UST filling point, LTW hose assemblies with TW couplings

ELAFLEX Hamburg

ERV pressure testing

Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling

Universal hose assembly for vehicles fighting dangerous goods incidents:

PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

ZVA HV for AdBlue®, SSB 16 SS / BS 16, SL 16 for AdBlue®

Urea solution (DEF, ARLA 32) for trucks: nozzle, Safety Break / Break Sleeve and hose assembly

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Rubber Expansion Joint ERV-BR 80.16

BR Expansion Joints, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products (e. g. carbon-blacks). Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e.g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR

ERV-G 50x160

Fuel mixer / blender

SVC 50-2"

Male hose coupling of steel with Spannloc clamps

ELAFLEX Hamburg

Assembling cell dispensing hoses

ERV Rubber Expansion Joints

Picture 3

ERV-R

"Red Band" Rubber Expansion Joints; pumping station

M 16-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, blue.

VK 50 SSE

TW male adapter. Material: stainless steel with universally resistant PFA coating (red)

Hose assemblies and Rubber Expansion Joints for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

Bunker boat: FHD flat laying hoses, HD hoses

Hose Reels electrical rewind system yellow

for water

Safety Swivel Break

SSB 16.0

Loading Brine (salt solutíon for winter service): CHS hose asssembly, DDC Dry Disconnect Coupling
