Road tanker with hose reel -
Quick change system between ZV 500 and ZVA 32 nozzles via DDC Dry Disconnect Coupling
AKD 19 Hy
CouplingSeal CSM
UTS hose assembly with AMKC 25 SS/SS
'Camlock' stainless steel coupler to EN 14420 - 7 with hose tail and Spannloc stainless steel clamps
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 ACME nozzle, LPG 16 hose
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
VB 80 ADR SS / VB 100 ADR Al with pressure relief
Plug for TW female couplers
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
ERV-G LT 100 TW
for low temperature applications
ERV-G 80.TW
"Yellow Band" Rubber Expansion Joints; tank truck
MB 80 SSE
TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
HD-C, underwing nozzle
Aircraft refueller, large reel with aircraft refuelling hose and underwing nozzle
ZVA 32 for aircraft refuelling
black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly
Camlock Cam Locking hose tail AMK-St 50 Ms and male adapter AVK 50-2" Ms (brass)
ELAFLEX Hamburg
Mini Installation instructions, on request
FSH flame protection cover for ERV rubber expansion joints
Use e.g. in ship engine rooms
Hose assembly with MKX 75 SS and VB 80 SS
TW female coupler with Spannfix clamp, plug
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
Oasis FV103 90° Fill Valve with Bus & Truck Nozzle, for CNG
DDC-M 80 SS; SG 3", VC 75-3, Elaflon FEP 75, DDC-K 3" SS ADR
Epoxy resin loading with Dry Disconnect Coupling, sight glass and FEP universal hose. DDC cap with pressure relief at container tank outlet.
Production MannTek, Sweden
IBC unloading
Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.
GasGuard LPG nozzle GG30: optional Magnet in the guard
For contactless activation of dispensers with reed switch technology
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO UL with EA 866 scuffguard, LPG 16 hose
Compact Line HD 50, Hose Reel Spring Rewind
FEP 5O, MannTek DDC-M 5O SS
SG-COAX
Sight Glass for ZVA Slimline 2 GR
GasGuard LPG nozzle GG20
With long connector nut to access 'hard to reach' fill points. Economic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
Flexible bronze pipe connectors
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
ERV with FSH:
Flame protection cover (open)
ZVA Slimline 2
with Sight Glass
