ZVA Slimline 2 and ZVA Slimline 2 GR, blue, with Splashguard and Safety Break Couplings
M 16-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, red.
AMKX 50 Ms
'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannfix clamps
ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, red.
Oasis FM104 Fuel Manifold on Natural Gas powered vehicle
Simultaneous Refuelling/Filling of Diesel and AdBlue®
Picture 1
ElaSil® Silicone hose assemblies DN 13-102
For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection
Marine bunkering and cargo hoses
offshore supply
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
ZVA 25, Slimline hose assembly
Truck refuelling
LPG Autogas dispenser, ZVG 2 ACME nozzle, LPG 16 dispensing hose
Underwing refuelling A 380
DDC-V 50 SS
MannTek Dry Disconnect Coupling, DN 50, stainless steel, with BSP thread connection
AKD 75 Hy
CouplingSeal CSM
Hose Reel with hydraulic rewind system blue, TW 100, DDC-M 100
SSB 25 Safety Break: Abriss
Aljac Closed Circuit Sampler (CCS), Carter Underwing Nozzle, bonding reel
Airfield refueller
TW hose for fire fighting vehicle with extremely long telescopic crane
Ship loading Naphta - STW 150 hose assemblies
Production MannTek, Sweden
Ship bunkering
FHD hose assemblies, Port of Gothenburg / Sweden
ELAFLEX Hamburg
Assembling COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading; detail
Refuelling equipment for petroleum based products:
Elaflex "Yellow Band" Hose assemblies, ERV Rubber Expansion Joints
Production MannTek, Sweden
M 19-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 19 SF hose Sulfur Free, black.
LPG 16 orange
Hose assembly for L.P. Gas, with anti-kinking sleeve and Colour Sleeve
ZVF 50 UL 91 / green
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.
H2 Hydrogen
H2 25 D Hydrogen hose, SFC 25, MX 25, VH 2
