Media Library / Images

Rail tanker discharge coupling KWK, with elbow DN 80

for damaged / dirty rail tanker or other threaded hose connections. Used e.g. for environmental protection trucks

M 21-1" NR cr

Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, red.

Camlock Cam Locking hose tail AMK-St 50 Ms (brass)

for the assembling with Spannfix or Spannloc clamps

Camlock Cam Locking male adapter AVK 50-2" Ms (brass)

HD 100 C, hydrant hose

Aircraft dispenser, pit

H2 Hydrogen

H2 25 D Hydrogen hose, SFC 25, MX 25, VC 25

DDC-K ADR:

DDC Dust Caps with Pressure Relief Valve to ADR Requirements. These pressurized dust caps PN 10 of aluminium for DDC male adapters on road tankers are much lighter than the PN 25 versions of stainless steel.

Guards for ZVA nozzles

suitable for all dispensers, world wide

ZVA Slimline 2, ZVA Slimline 2 GR (Special type with PowerPerformer)

ERV VSR:

ERV with vacuum support ring. Ring of AISI 316 Ti , used when the vacuum resistance of the chosen ERV is not sufficient.

Construction of Elaflex composite hoses type FWS

Sectioned view of a composite hose, denomination of the components - detail view

ERV-GR 80.16

GREEN BAND Rubber Expansion Joint for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.

IBC unloading

Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.

Quality in the detail: valve assembly of a ZVA Slimline 2 petrol station nozzle

KWZ 3" Al

Rail tanker adapter with male thread connection, aluminium

ERV-ROTEX expansion joint, hot water pumping system

Elaflon PTFE hose asemblies

Production MannTek, Sweden

Oasis company building

ARK 19 Safety Break (Hose Break) at LPG Autogas dispenser

Reassembly on site without tools

Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion

Picture courtesy of Macoil International, Gibraltar

Underwing refuelling, HD-C, aircraft dispenser

Hose assembly TW 75 with MKX 75.80 Ms

TW hose with TW female coupler, two piece

DGC-V 50 F SS for L.P. Gas, PN 25/40

Dry Disconnect Coupling with flange connection, DN 50, stainless steel, with rubber dust cap

Heating oil delivery: ZV 400 nozzle, HD reel hose

Hose Beads

BD 50, BD 63

Elaflon PTFE

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

DEC – Dry Evotek Coupling

Dry disconnect coupling for the chemical industry

GasGuard GG11R

The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.

Hose assembly for L.P. Gas

LPG 50, DGC-M 50
