Hose assemblies
for dangerous goods: ELAFLEX quality
ELAFLEX Hamburg
Visual quality checks
Oasis FM104 Fuel Manifold on Natural Gas powered vehicle
ZVA Slimline 2 GR
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
ELAFLEX Hamburg
Hose assemblies pressure testing (hydrostatic test)
Hose assembly TW 75 with MKX 75.80 Ms
TW hose with TW female coupler, two piece
GSD 50 PU
Coupling seal for TW couplings, polyurethane
RN 2 x 21/2" SS
Reducing nipple
ELAFLEX Hamburg
ERV inner protection sleeve/tube "SR"
Safety Crimping Ferrule of stainless steel
SH 50 SS
RS 21/2 x3 SS
Reducer Female/Male
ELAFLEX Hamburg
Assembling ERV large DN
HB 19 ST tar spraying hose
Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).
BD 63 Hose Beads
to EI 1522 standard - notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
Offshore FSRU (Floating Regasification Unit), connector for gasoil sludge / seawater
DDC-V 150 F
Ship bunkering
HD hose assembly on dispenser vehicle
ERV-G ... TW
Dispenser / hydrant inlet pipe
DCC Dry Cryogenic Coupling for LNG
Coupling process
DDC-V 50 F Aseptic
MannTek Dry Disconnect Coupling, DN 50, stainless steel, with Aseptic flange
IBC unloading
Coupling of Chemopal chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-adapter RS 60 x 2 SS.
DAC-V 65
Aircraft refueller, Dry Aircraft Coupling to ISO 45 for bottom loading
ELAFLEX Hamburg
Construction
Oasis BV 708 1" Ball Valve for CNG
ZVA Slimline 2 GR, Coax hose assembly
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
SG 1" 1x0 Al
Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
Slimline 16 green
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
UTS hose assembly with AMKC 32 SS and AVKC 32 SS
'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps
Camlock Cam Locking hose tail AMK-St 50 Ms (brass)
for the assembling with Spannfix or Spannloc clamps
ZVA Slimline 2 nozzle with hose assembly
V-St 50 SSE
Male threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
