Media Library / Images

ELAFLEX Hamburg

Certificate pressure test

HD 100 C, hydrant hose

Aircraft dispenser, pit

Fuel delivery at the petrol station

LTW 75 fuel delivery hose, MKX 80 female TW coupler

MK 80 SS, TW couplers stainless steel

Underwing refuelling, HD-C, aircraft dispenser

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry

Dantec Production hose

Composite hoses

ERV ZS:

Tied Flanges – Type ZS, Tie rods with outer limitation in rubber bushings

ZVA Slimline 2 GR

with red scuffguard; CSB 21 Coax Safety Break with BS 21 Break Sleeve; Slimline COAX hose assembly

Rubber Expansion Joint ERV-GS 80.16

YELLOW STEEL expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Temperature (depending on medium) range - 20° C up to + 90° C, temporarily up to + 100° C. Fire resistant (to ISO 15540) up to 30 min. and 800° C. Electrically dissipative.

Safety Swivel Break SSB 16 SS of stainless steel f. ZVA AdBlue® HV

new design

ZVA Slimline 2 LA with LeverAssist hold-open aid

NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)

Nozzle boot f. ZVF 50 with additional spout retainer

ZVA Slimline 2 GR, special type with bellows, black, guard 3 - side view

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

AN Rd 78 SS

Welding nipple with foodstuff thread, stainless steel

Hose tube of road tanker for chemicals

MK-A 80 SS with active safeguard lever ; VB 80 SS dust plug

GasGuard GG11R

The GasGuard GG11 Back-Check Valve (GG11R: with additional release screw) should be standard equipment for any LPGas road tanker operator. It is used in conjunction with LPGas bulk refueling nozzles to contain leaks at storage tank fill points. If the fill point proves to be leaking when removing the nozzle it can be left on the tank until corrective action is taken. The driver can move to the next fill point without delay.

Oasis Fill Valves at CNG service station

ZVA_AdBlue®_LV_2-Stufen-Anschlag_Step2_mod

Use - 2/2

MK 50 SSE

TW female coupler stainless steel, with PFA coating (red)

Assembling "ZS" tie rods to ERV rubber expansion joints

Oasis BV708, 1" ball valves, isolation valves, CNG trailer loading

Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle

Low Temperature types

Ship bunkering with LNG

CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media

VSR vacuum support ring for ERV Rubber Expansion Joints

to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C

LNG Refuelling

N-LNG Nozzle, push handles to couple

Ferrule threaded hose coupling M 19-1" cr

for petrol station dispensing hoses
