LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
Unloading LNG road tanker
DCC Dry Cryogenic Coupling
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
Rubber Expansion Joint ERV-G LT 80.16
YELLOW BAND LT expansion joints designed for low temperature applications for standard-conform petroleum based products, e.g. diesel, heating oil up to + 90° C, aviation fuels, petroleum up to + 60° C and gasoline up to + 40° C. Temperature (depending on medium) range - 40° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Oasis PM104 Priority Panel / Manifold, for CNG
For long and heavy aviation refuelling hoses: Hose Beads 'BD' to EI 1522 standard
They notably improve handling as they reduce friction against the tarmac. They additionally protect against hose abrasion. 'BD' Hose Beads are highly break resistant, contain no bolts or nuts, can be easily assembled or disassembled and are suitable for reeling.
ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies
Maroc
VK 80-2" AG Ms
TW male coupling brass, with reduced male BSP connection (special type)
DDC-V 50 SS F, DDC-K 50 blue (for AdBlue®)
GasGuard LPG nozzle GG1EH
used for industrial refueling / attended refueling. With hybrid nose piece − low lever force. Release volume on valve closure: 1,7 cm³.
Chains K 160, K 160 SS, K 180 L, K 200, K 200 SS, K 260 L, K 300, K 300 SS, K 360, K 360 SS
Connection between coupling and dust cap / plug
IBC
with CHS chemical hose assembly
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
and Sight Glass SG 1 Al / Slimline dispensing hose
Coloured hose assemblies for the forecourt
Slimline 21, M 21-1" NR
Elaflex Cam and Groove Couplings ('Camlock'): AMKX 50 EASY
EASYLOC stainless steel coupler to EN 14420 - 7, with lever arrest. Picture shows the version as one-piece coupler with integrated hose tail and Spannfix stainless steel clamp
Grafik ARK 19
Safety Break for LPG (Autogas) dispensers. Hose Break. Reassembly after separation without tools.
KR 50 - 21/2"
Filling of Heating Oil Tanks: New Adapter for difficult-to-reach house connectors
V 19-1" SS
Male ferrule hose coupling EN 14424 stainless steel, reusable. Slimline 19 SF (sulphur free) hose, black.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Manufacturing of turned parts
ZVF 50 JET for aircraft refuelling
with EA 951 PTL black, SC 50 Al, HD 50 C and BD 50
ElaSil® Silicone hose assemblies DN 13-102
For Pharma, foodstuff and cosmetics industry.
ELS 25 with Camlock Cam Locking Coupling, foodstuff thread and Triclamp.
ZVA Slimline 2
Automatic nozzle DN 19, for flowrate max. 80 l / min. Green Product Sleeve and Scuffguard, Slimline dispensing hose assembly
Oasis FV103 Fill Valve, CNG dispenser
KR 50
bend with VK 50 x MK 50, 60°
MannTek DCC-V & DCC-M Dry Cryogenic Couplings
Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer
ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1
Hose Reel with hydraulic rewind system orange, LPG 32, DGC-M 50
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
