LPG ship-to-ship cargo transfer
Danchem PASS composite hose
ROTEX Rubber Expansion Joints
Locomotive
TSG 3" Rg
tank truck sight glass type TSG 3", one end TW tank truck fl ange according to DIN 28459, other end male thread
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room; Netherlands
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
MannTek FFBV
Full Flow Ball Valves 2-way
Flexible bronze pipe connector BWO
Installed in manhole of a petrol station underground storage tank (UST). Suction pipes towards the dispenser pumps
ERV-R
"Red Band" Rubber Expansion Joints/ Osmose
ERV-R 80.16 SS TA
Red Band Rubber Expansion Joint with "TA" PTFE lining
ERV-OR 65.25
ORANGE BAND Rubber Expansion Joint for Liquid Petroleum Gas (LPG) acc. to EN 589. For tank trucks and refuelling stations. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically dissipative.
Ship bunkering with STW hose assembly and MannTek DDC Dry Disconnect Couplings
Scandinavia
Safety Swivel Break
SSB 25
ZVG 2 EURO nozzle for L.P. Gas / Autogas
with EA 866 scuffguard black and LPG 16 S hose assembly orange
Elapharm clamp fittings
Fixed Flange and hose tail of stailess steel
SFC 63.16 SS
Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling
Storz Safety Coupling SHK
upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.
SG 1 1x0 SS for Nozzles for AdBlue®
Attach on dispenser side of swivel
Polypal Oil 75
Universal chemical hose special type with petroleum resistant cover of Chloroprene (CR). Suitable e.g. as gantry hose (road tanker loading).
Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400
for alcohol
KWZ x MK 80-32°
Rail car adapter with TW coupler, bent lever
SPANNFIX pinned safety clamps of stainless steel
SX 75 NR SS
Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle
Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt
H2 Hydrogen
ERV-H2+ DN 80
Oasis TH Tank Head Valve, for CNG
Production MannTek, Sweden
ZVA Slimline 2 GR with splashguard, hand
scuffguard and Splashguard green, Slimline hose assembly with Colour Sleeve green
ZVA Slimline 2 GR, black, guard 3 - side view
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
ERV Rubber Expansion Joints
Picture 2
