ERV-G 80.TW
ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers
ELAFLEX Hamburg
Assembling Coax hoses
DAC-V 65, DAC-M 65
Coupling test facility
ZVA Slimline 2 with SG 1" Al Sight Glass
Ship bunkering
'Yellow Band' collapsible high
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
Hose tube of road tanker for chemicals
MK-A 80 SS with active safeguard lever ; VB 80 SS dust plug
ERV-G
with vacuum support spiral
ELAFLEX Hamburg
Main building / entrance
Filling plant for special gasoline types
ZVA 25 solvent type with special seals, Slimline hose assemblies
ELAFLEX Hamburg
Hose stock
AKD-Hy
Coupling seal type AKD for cam locking couplings EN 14420-7. Here: of CSM
LBS 75 hose assembly for foodstuffs, FDA conform
with VC 50 SS male coupling, Spannloc clamps
ERV-GR 80.16 ZS 2
GREEN BAND Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
Oasis HC308 Ultra Fast Quick Fill Coupler, SAE male, for CNG
DAC-V 65
Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading; detail
Rubber Expansion Joint ERV-GS HNBR 80.16
YELLOW STEEL HNBR expansion joints for petroleum based products, DIN EN fuels up to 50 % aromatic content, cooling water with oily anticorrosion additives, lubrication and hydraulic oil, seawater. Very good aging, weathering and ozone resistance. Temperature range (depending on medium) - 35° C up to + 100° C, temporarily up to + 120° C. Fire resistant to ISO 15540 up 30 min. at + 800° C. Electrically dissipative.
HD-C Neon, large reel, VK 100 Ms, MB 100 Al
ZVA 25, bus refuelling
Forklift refuelling with LPG (L.P. Gas, Autogas)
GasGuard nozzle, LPG 16 hose; dispenser
ELAFLEX Hamburg
Visual quality checks
ZVF 50 JET
with HD-C NEON hose assembly
ZVG 2 EURO nozzle for L.P. Gas / Autogas, LPG 16 hose assembly
Vehicle refuelling with LPG (L.P. Gas, Autogas)
ZVG 2 EURO, LPG 16 hose; Spain
Ship sided connectors for bunkeringof fuel, lube oils, fresh water; unloading of sewage
DDC Dry Disconnect Couplings with caps
ERV-W 80.16
WHITE BAND Rubber Expansion Joint for foodstuffs, also containing oil and fat. Liner corresponds to Recommendation XXI of BfR and FDA-21CFR 177.2600. Not approved for drinking water. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to 100° C. Electrically non-conductive.
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle (shut off by limit switch), HD hose assembly, road tanker
DCC Dry Cryogenic Coupling for LNG
Coupling process
ROTEX 80.16
Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative
