ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Cabinet of road tanker:

hose tubes, MK 100, MK 80, hose assemblies

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

Swivels DG 25 SS, DG 38 SS, DG 50 SS with hose assembly

Swivels serve to avoid hose torsion (increase of life span) and help for easier handling

TGN 2" Al (TGN 50 Al)

Tank truck flange aluminium, one end flange to DIN 28462, other end male BSP thread.

Locomotive refuelling

Dispenser, ZV 32 DB nozzles with Renk coupling

ERV-GR ... ZS

"Green Band" Rubber Expansion Joints with limiters in chemical pumping system

Oasis FV103 Fill Valve, CNG service station

TSVX 50

Hose connectors with double shank of hot stamped brass, with Spannfix safety clamps of hot stamped aluminium.

UTS hose assembly with AMKC 32 SS and AVKC 32 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7 with hose tail and Spannloc clamps

Storz Safety Coupling SHK

upon uncoupling, the safety dust plug first falls into holding claws, relasing an eventual pressure within the system. Only then the dust cap can be fully taken off. - increased protection for the operating personnel. Easy to use, no additional pressure release necessary, slim design, does not build up, no freezing up in the dome section.

Fluorline EFL 16

Universal pump hose DN 16 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue^® urea solution. Temperature range -40 °C to +100 °C. Burst pressure > 64 bar.

AMX ammonia hose

rail tanker Loading/Unloading

ELAFLEX Hamburg

ZVA Slimline 2 GR

ERV-G 100.16

YELLOW BAND Rubber Expansion Joint suitable for petroleum based products with aromatic content up to 50%, fuels (ethanol content up to 85 %), aviation fuels, town gas and natural gas except liquefied petroleum gas. Temperature range (depending on medium) - 20° C up to + 90° C, temporarily up to + 100° C. Electrically dissipative.

ZVG 2 DISH nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break

Elaflon PTFE 50 with FFX 50 SSE/SS; PCS 25 with AMKC 25 SSE/SS

Universal hoses with PFA coated fixed flange and Camlock fittings. Spannfix / Spannloc stainless steel clamps.

Hose Safety Break for LPG

ARK 19

Construction site / on site refuelling:

ZVA 500 manual bulk nozzle

Oasis FV103 Fill Valve, CNG refuelling

AKD 19 Hy

CouplingSeal CSM

ZVA Slimline 2, guard no. 4, Sight Glass SG 1 Al, Slimline hose assembly

Elaflon Plus FEP 50

AMKX 50 Ms

'Camlock' brass steel coupler to EN 14420 - 7 with hose tail and Spannfix clamps

ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid

TW Couplings with Isolation for electronic Cross-Over Prevention Systems

see Information 4.12

Vehicle refuelling with LPG (L.P. Gas, Autogas)

GasGuard GG1 nozzle, Butapal hose

Filling of Heating Oil Tanks: Adapter KR 50-2 3/4" (Switzerland)

for difficult to reach filler inlets

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 22

Aircraft refuelling hose with reflecting stripes, Hose Beads 'BD' which notably improve the handling as they reduce friction against the tarmac, next generation overwing nozzle ZVF 50
