Oasis CNG refuelling equipment:
Ultra Fast Fill System (Diagram, English)
DDC-M 100, HD-C, airport depot
Dry Disconnect Coupling, Yellow Band hose, at airport depot
VX 50-2" NPT SS
Male hose coupling 2" NPT of stainless steel with Spannfix clamp
ZVA Slimline 2 LA nozzle with LeverAssist hold-open aid
LeverAssist reduces the hold-open force by 90%, for comfortable refuelling in countries where latching is not allowed
SG 1" 1x0 Al
Sight Glass with propeller, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.
ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red
Thailand
ZVF 50 helicopter refuelling
France
IBC
with CHS chemical hose assembly
SC 50 SS
Spannloc clamps, stainless steel
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
LPG terminal: loading with DGC Dry Gas Couplings
ERV-R
"Red Band" Rubber Expansion Joints/ Osmose
ERV-G Yellow Band rubber expansion joint, wind turbine (hydraulic oil)
Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)
ZV 400
High performance manual operated dispensing nozzle. Special type with stainless steel swivel DG 40 SS
ERV-CR
"CR" Rubber Expansion Joints - installation in sewage plant
NB-ZVF 50 SR, ER 583 PTL, Aljac Closed Circuit Sampler (CCS)
Nozzle boot f. ZVF 50 with additional spout retainer
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
ERV-D
Rubber Expansion Joints Type ERV-D DN 200 - 4200, single or multi-sphere bellows. Here: DN 3600
Universal hose UTS 50
ERV-G 100 TW
ZVG 2 DISH
Nozzle for L.P. Gas / Autogas, with 'Italian' Claw Coupling. Pictured: coupling open / closed
Oasis FV103 45° Fill Valve with NC 203 P36 Nozzle, for CNG
KWZ x VK 80
Rail car adapter with TW male coupling
Adapter: MK 80-32° Ms x MK 80-32° Ms
Special type with bent levers. The lever is bent to enable lever arrest (safe position when coupled)
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose
Elaflon Plus FEP 50
Fuel delivery at the petrol station
LTW 75 fuel delivery hose, MKX 80 female TW coupler
ERV-GR ... ZS
"Green Band" Rubber Expansion Joints with limiters in chemical pumping system
