Media Library / Images

ERV-CR

"CR" Rubber Expansion Joints - ballast water treatment skid

Ship bunkering with LNG

CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media

Fuel Grade Identification to EN 16942 for ZVA Nozzles

Type EK FGI - attach with Product Badge EK 145

Large hot stamping machine, production of aluminium parts

HD-C, ZVF 50, Refueller

Aircraft refueller, overwing refuelling JET

ZVA Slimline 2, guard no. 8D, black scuffguard, red product sleeve, SL 16 hose assembly with red colour sleeve

Slimline 16 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

Example of a marking of test data (hydrostatic test) of a hose assembly

Rubber Expansion Joint ERV-CR 80.16

CR Expansion Joints for cold and warm water, swimming pool water, sea water, waste water (weakly sour or alkaline) also oil containing, cooling water with protective oils against corrosion, lubricating oil, grease and air, compressed air. Temperature range (depending on medium) - 25° C up to + 90° C, temporarily up to + 100° C. Electrically non-conductive.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Assembling ZVA components

Oasis 3/4" Ball Valve for CNG

Boat refuelling

ZVA Slimline 25, HD hose assembly

DDC-V Dry Disconnect Couplings for various media

tank storage; TW hose assembly

Aircraft refuelling

Carter Underwing Nozzle, HD63C Neon, ZVF 50 JET, SC 50 Al, HD 50 C, Hose Bead BD 50

Slimline 21 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Hose assemblies and Rubber Expansion Joints for the chemical industry

ERV-GR TA, UTL with DDC, FXD with male thread, Elaflon Plus FEP with foodstuff fitting, Elaflon PTFE with female thrad

AVKI 38 SSE

Camlock male adapter. Material: stainless steel with universally resistant PFA coating (red)

ELAFLEX Hamburg

Assembling Spannloc hose clamps

Fluorline EFL 21

Universal pump hose DN 21 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue^® urea solution. Temperature range - 40° to + 100° C. Burst pressure > 64 bar.

TW hose for fire fighting vehicle with extremely long telescopic crane

ZH 50 nozzle with MK50SS + HD hose assembly, DDC-V 80 Ms with cap, MK 80 Ms with VB 80 P

Urea solution filling, truck: ZVA HV for AdBlue® nozzle

ZVA Slimline 2 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

DCC Dry Cryogenic Coupling for LNG

Coupling process

Yellow band aircraft refuelling hose, hose coupling with male thread, Spannloc aus Aluminium

HD 50 C, VC 50 SS, SC 50 Al

AMKC 50 SS

'Camlock' stainless steel steel coupler to EN 14420 - 7 with hose tail and Spannloc clamps

Dust caps and plugs for MannTek Dry Disconnect Couplings

Lube oil filling, ZV 19 manual nozzle

HD-C aircraft refuelling hose

HD 50 C F

Rubber Expansion Joint ERV-R 80.16

RED BAND expansion joints for water, drinking water (approvalDVGW W 270 as well as ACS, conform to FDA), cold and warm waste water, seawater, cooling water, also with chemical additives for water treatment, low concentrated acids and alkalis, salt solutions, technical alcohols, esters and ketones. Can be used in oily athmospheric environments, e.g. engine rooms. Temperature (depending on medium) - 40° C up to + 100° C, temporarily up to + 120° C. Electrically dissipative.
