MannTek FFBV

Full Flow Ball Valves 2-way

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

Stainless steel Hose Reel with pneumatic rewind system, FWS 50 PP

ERV-G 80.TW

Yellow Band rubber expansion joint with TW flanges

TS 80 lockable cap vor VK 80 couplings

Hose Connection with TW coupling, TSG 3" Sight Glass

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Elaflex refuelling equipment:

Quality is in the detail.

Elaflex hoses

PTFE, FEP, HD, UTS

Hose Reel f. marina terminal, Manual Rewind

TW hose assembly

Alternative fuels: HVO (hydrotreated vegetable oil) and E 85 (gasoline with up to 85% ethanol)

ZVA Slimline 2, ZVA Slimline 2 GR

Elaflon Plus FEP hose assembly with KSS anti kinking sleeve

flange hose fitting with special coating

Production MannTek, Sweden

Hose assemblies

Polypal Clean with RMC, LPG with ACMX, Polypal Plus with SFC-SS, Tecnopal with MK-SS

Adapter coupling DGC / ACME

DGC-V 50 x 1 3/4" ACME. Dry Disconnect Couplings are state of the art for the fast and safe loading/unloading for liquefied gas (LPG). Connecting with standard fittings is still possible with adapters, like this one with ACME thread.

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Assembling hall, meterial logistics

ElaSil® Silicone hose assemblies DN 13-102

For for high media purity requirements, easy to clean. Suitable for Pharma, foodstuff and cosmetics industry. Homogeneous hose construction of platinum cured, translucent and phtalate free Silicone (FDA / USP), resistant to kinking and highly flexible. Large temperature range -60° C to +200° C. Available as complete hose assembly with crimped fittings, DN 13 to 102. Here: DN 25 with Camlock Cam Locking Coupling and Triclamp connection

Slimline 16 black

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.

AMX 50 PA

Ammoniac hose to EN ISO 5771 for water-free, liquid and gaseous ammonia.

DAC-V 65, DAC-M 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading - in action

GasGuard LPG nozzle GG30

4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C

AdBlue® urea solution, road tanker:

DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel

LNG Refuelling

N-LNG Nozzle, push handles to couple

Oasis BV Ball Valves range for CNG

ERV-CR 100 (4")

'CR' Rubber Expansion Joint for cold and warm water / ship engine room

Elapharm EPH 25 with foodstuff fitting DIN 11551, free of dead spaces

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Nozzle boot NB-GG

for GasGuard LPG nozzles

ELAFLEX Hamburg

Offshore Methane gas production

UTS / CHS hose assemblies
