1614 images found




SG 80-TW1 Al

SG 80-TW1 Al

Sight glass with rods, with TW flanges to DIN 28460

ERV-D

ERV-D

Rubber Expansion Joints Type ERV-D DN 200 - 4200, single or multi-sphere bellows. Here: DN 3600

AKD 19 Hy

AKD 19 Hy

CouplingSeal CSM

SG-COAX

SG-COAX

Sight Glass for ZVA Slimline 2 GR

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

Marking of High Temperature Types ZVA Slimline 2 / ZVA Slimline 2 GR

For regions with exceptionally hot summer conditions which may lead to particularly high fuel temperatures we offer High Temperature (HT) nozzle types, available for ZVA Slimline 2 and ZVA Slimline 2 GR.

Underwing refuelling, HD-C hose assembly

Underwing refuelling, HD-C hose assembly

Russia

Ship bunkering with LNG

Ship bunkering with LNG

Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling

ERV-R 200x175.16 ZS 4

ERV-R 200x175.16 ZS 4

Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)

Elaflex Hiby Tanktechnik, Production Plettenberg / Germany

Elaflex Hiby Tanktechnik, Production Plettenberg / Germany

Plettenberg factory 1

Underwing refuelling, HD-C hose assembly

Underwing refuelling, HD-C hose assembly

ZVA Slimline 2 GR

ZVA Slimline 2 GR

Automatic nozzle with vapour recovery, flowrate up to 45 l / min.

CBC-PERC 100

CBC-PERC 100

Cryogenic Breakaway Coupling "PERC" for LNG after pneumatic separation

MannTek DGC-M & DGC-V DryGasCouplings

MannTek DGC-M & DGC-V DryGasCouplings

the alternative to ACME and flanged connections

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

Oasis BV708, 1" ball valves, isolation valves, CNG spheres (tanks)

SG 1" 1x0 Al

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Mobile tank for solvents

Mobile tank for solvents

hose assembly UTS 50 with MKX 50 SS and VB 50 SS

Elaflex Hamburg

Elaflex Hamburg

Mini Installation instructions, on request

ZVF 40 with EKG and GKG

ZVF 40 with EKG and GKG

Manual aviation fuelling nozzle for overwing service. With bonding cable and dust cap assembly. Note, this type is going to be replaced by ZVF 50

Tank truck and trailer with HD 45 hose reel, ZV 500 nozzle

Tank truck and trailer with HD 45 hose reel, ZV 500 nozzle

ERV-G ... TW

ERV-G ... TW

Aircraft refueller

Underwing refuelling, HD-C hose assembly

Underwing refuelling, HD-C hose assembly

Hydrant dispenser

MK 50 SSE

MK 50 SSE

TW female coupler stainless steel, with PFA coating (red)

Upstream Oil Industry, TW hose assemblies

Upstream Oil Industry, TW hose assemblies

Kuwait

Unloading petroleum products at the service station (road tanker to UST)

Unloading petroleum products at the service station (road tanker to UST)

LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
