oasis TH Tank Head Valves, CNG trailer
M 16-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 16 hose, black.
TW 100, DDC-M 100, airport depot
Dry Disconnect Coupling for Loading/Unloading
HD 100 C Neon, HD 10 sensing hose
Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.
Motorcycle refuelling at the petrol station
ZVA Slimline 2 GR with special short spout
ELAFLEX Hamburg
Assembling dispensing hose fitting
RMX 32 SS / SS
Spannloc threaded hose coupling with foodstuff thread / Spannloc of stainless steel
DDC-M 100-4" with TW 100 hose assembly
Dry Disconnect Coupling and road tanker hose
ZVA Slimline 2, dispenser
MK 80 Ms
TW coupler of brass, to EN 144260-6 with 3" female BSP connection
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
Solvapal 32
Solvent hose to EN 12115 for most solvents, paints (also waterbased), water laquer, petroleum products, alcohols, alede hydes, esters and ketones. In short term operation also suitable for aromatic und chlorinated hydrocarbons.
Fuel delivery at the petrol station
LTW 75 fuel delivery hose
ZVF 50 JET
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C
Accessories and spare parts: Ground cable assembly, dust cap assemblies, spouts, strainer
ER 339, ER 494, ER 495, ER 587 JET PTL, EKG 1200, GKG 19, GKG 32, GKG 38-J, ES336.1
ERV-R Red Band rubber expansion joint, ship engine room
Sample Collection Unit
DDC-M 25 Dry Disconnect Couplings and HD hose assembly for sample collection of aircraft fuel
Slimline 21 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.
ERV-G 150.TW, ERV-G 80.TW
Aircraft refueller
Camlock Cam Locking hose tail AMK-St 50 Ms and male adapter AVK 50-2" Ms (brass)
ELAFLEX refuelling equipment:
Quality is in the detail.
ERV-OR ... ZS
"Orange Band" Rubber Expansion Joints with limiters; heating plant
Locomotive refuelling
ZV 32 DB nozzle with Renk coupling
ELAFLEX Hamburg
Stock special flanges, pick by voice
Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle
Low Temperature types
Elapharm EPH 25 OHM-G with ASFB hose tail
Stainless steel hose tails - new shape
Stainless steel hose tails - optimized shape for enhanced operational safety, suitable for temperatures up to 150° C. Details see Information 5.15.
Fuel Grade Identification to EN 16942 standard, direct print on product badges for ZVA Nozzles
Picture 2
ZVA Slimline 2 GR, black, guard 3 - top view
ELAFLEX Hamburg
ERV pressure testing
