Camlock hose couplings: system comparison
Easyloc from Elaflex with automatically secured levers.
Unloading: MK couplers with DDC-V 80 adapter
Elaflex Pacific (Australia)
Manufacturing GasGuard GG1 nozzle
Elaflon PTFE 50
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
Elaflex AB, Sweden
Unloading road tanker
TW hose assembly, DDC Dry Disconnect Coupling
ERV SR:
ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.
LH2 Refuelling
'N-LH2' nozzle for LH2 truck refuelling of cryogenic hydrogen
ElaSil® Silicone hose assemblies
Connecting Triclamp
IBC connection with reducer RS S100x3" SS
MannTek DDC-V 80, DDC-M 80, FWS 75 PP
Petrol station in Singapore
ZVA Slimline 2 nozzle with Splashguard, SSB 16 Safety Break, Slimline hose assemblies
MannTek DCC-V & DCC-M Dry Cryogenic Couplings
Hose assemblies for petroleum based procucts
LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
EASYLOC Cam Locking Coupling
easy deactivation of lever arrest
COAX Safety Break
CSB 21
Slimline 16 yellow
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
ERV-OR
"Orange Band" Rubber Expansion Joints, road tanker
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, yellow.
SVC 50-2"
Male hose coupling of steel with Spannloc clamps
Elaflex LTW hose assembly, Matterhorn
Supply of the mountain top station via IBC unloading
Adapter: MK 50-45° SS x VK 50 SS
The lever is bent to enable lever arrest (safe position when coupled)
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
Elaflex hoses
HD, TW, LPG, FXD, SL, FEP, CHS, LMS, UTS, PTFE, PCS
Assembling Spannloc hose fittings
GasGuard LPG nozzles
and LPG 16 orange hose assemblies for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane.
Elapharm EPH 25 with foodstuff fitting DIN 11551, free of dead spaces
Underwing aircraft refuelling
TW 100, SFC 100 TW, HD 63 C Neon
