Media Library / Images

Automatic lathing machine, production of brass swivel parts

Road tanker Sweden

large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)

Elaflon Plus PTFE 38

Filling of small containers for chemicals

Tank storage, mixer: LTW hose assemblies

V 19-1" cr

Male ferrule hose coupling EN 14424, reusable. Slimline 19 SF (sulphur free) hose, black.

ERV-BR 100.16

BR Rubber Expansion Joint, special type for abrasive media such as sludges, slurries, solid / liquid mixtures and emulsions, dustlike or powdery products. Also suitable for all kinds of water (non oil containing) as well as various chemicals. Not suitable for petroleum based products. For extreme strain (e. g. sharp and rough-edged matter) we suggest the use of ERV with inner protection sleeve type SR.

Universal hose assembly for vehicles fighting dangerous goods incidents:

Aspiration hose PTFE 32 length 2,1 mtr., one side VKC 32.50 SS/Vi SS, other side open

Road tanker with large reel, HD hose assembly, ZV 500 nozzle

M 63 2½" SS, TD 76/63 PTFE, Spannloc SC 63 Al

Hose coupling with female thread, Spannloc aus Aluminium

ElaSil ELS 38 with DIN 11851 hose fitting, FREE OF DEAD SPACES

ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany

Sand casting

MK 80-90 SS; MK coupling stainless steel with bent lever 90°

TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

VKC 75 SS

TW male hose coupling, stainless steel, one part, with Spannfix clamps, with protecting "K"-Ring

VB 100 ADR Al with pressure relief

Plug for MK 100
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

Oasis BV708, 1" ball valve / isolation valve, CNG fill post for trailer loading with HC200 Quick Coupler

HD-C, airport depot

Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot

Slimline dispensing hose SF (sulfur-free)

Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose

Ship bunkering

Taking probes; VK coupling

Camlock cam locking couplings:

Attachment AVB dust plug with chain to Spannloc clamps (service free of charge)

Loading Brine (salt solutíon for winter service): CHS hose asssembly, DDC Dry Disconnect Coupling

LNG Refuelling

Vent Coupling 'VC-LNG'

Mobile tank for solvents

hose assembly UTS 50 with MKX 50 SS and VB 50 SS

Integrated Diesel Drip Catcher for ZVA Slimline 2

Scuffguard for ZVG 2 nozzles: type EA 866

with integrated fuel grade identification to European rules and large advertising/printing surface. Available in orange and black

GasGuard LPG nozzle GG20DN

With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.

Boat refuelling, Hose Reel, ZVA Slimline 2

Ship bunkering with LNG

CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media

Heating oil delivery: ZH 50 nozzle, HD reel hose

FSH flame protection cover for ERV rubber expansion joints

Use e.g. in ship engine rooms

VHD Neon aircraft refuelling hoses

Aircraft dispenser
