ELAFIX 40

Magnet adapter for installation in filler necks from DN 40. This adapter allows the refilling of urea solution with ZVA AdBlue^® HV, without the risk of misfillings. Meets ISO 22241-4.

Hose assembly for petrol stations

Standard hose SL 16

ZVA Slimline 2 without scuffguard: body markings

RS 4 x 51/2 SS

Reducer Female/Male

ELAFLEX hose quality: seamless liner

ZVF 50 JET

VB 80 SSE

TW dust plug of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Rubber Expansion Joint ERV-GR 80.16

GREEN BAND expansion joints for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.

ZVG 2 EURO UL nozzle for L.P. Gas / Autogas

with EA 866 scuffguard black and LPG 16 S hose assembly black

Aircraft refuelling hoses

VHD-C NEON, SFC TW, HD-C NEON, MC SS Al, PHD-F, VC SS Al

Pipe with AVKI 50 SS, hose assembly with AVKX 50 SS

'Camlock' stainless steel female and male coupling to EN 14420 - 7

ELAFLEX refuelling equipment for LPG (Autogas, L.P.Gas)

ELAPHARM Type EPH 25

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

LPG road tanker loading with MannTek SBC Safety Breakaway Couplings

Camlock couplings:

stainless steel female and male couplings to EN 14420 - 7

ZV 400, HD hose assembly on road tanker

SMS 19-3/4"

Steam hose couplings of steel to EN 14423. With bolted clamps of hot stamped brass. For saturated steam hoses up to 220° C, compressed air, oxygen, oils up to 25 bar W.P. Hose tail and union nut of steel Zn / Cr.

Manufacturing warm forged parts

Example SC 150 Spannloc clamp

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

Universal hose UTL 50

ZV 500

High performance manual operated dispensing nozzle with 'TW' coupling MK 50 for Diesel, fuel, oils, petroleum

ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch

Fluorflex FXD universal hose assemblies

with inner corrugation for maximal flexibility. Picture 1

ERV Rubber Expansion Joints

Picture 4

Tank container filling coupling: MK 80-32 SS with VB 80 SS

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

IBC

with CHS chemical hose assembly

Adapter coupling DGC / ACME

DGC-V 50 x 1 3/4" ACME. Dry Disconnect Couplings are state of the art for the fast and safe loading/unloading for liquefied gas (LPG). Connecting with standard fittings is still possible with adapters, like this one with ACME thread.

LNG ship bunkering

DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling

Vehicle refuelling with LPG (L.P. Gas, Autogas)

ZVG 2 DISH nozzle

ERV VSD:

ERV with vacuum support spiral. Spiral of AISI 316 Ti, used when the vacuum resistance of the chosen ERV is not sufficient.
