ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies
Petrol station, Indonesia
Hose assemblies
for petroleum based products, chemicals, foodstuff and pharmaceuticals, LPG
Maintenance at the petrol station
Type PCS, Polypal Clean
one side with RMC foodstuff fitting / Spannloc clamps stainless steel, other side open (note the inner conductive stripe)
ELAFLEX Hamburg
Hose assemblies, marking after testing on the fitting
TW connecting hoses
airport depot, gantry
HD 100 C, HD 10 sensing hose
Aircraft Dispenser with DN 100 hose (spiralised marking) and a sensor hose to control the hydrant system.
AdBlue urea solution, road tanker:
DDC-M 50 Dry Disconnect Coupling, UTL 50 hose assembly on reel
MK "TW" female couplers of stainless steel
special types with bent lever
ELAFLEX Hamburg
ERV marking after test
Road tanker with hose reel -
Quick change system between ZV 500 and ZVA 32 nozzles via DDC Dry Disconnect Coupling
Construction site / on site refuelling:
ZVA 32 (automatic nozzle), road tanker
CNG Safety Break (Hose Break)
connected
ERV-G ... TW
Aircraft refueller
ZVA AdBlue HV, SSB 16 SS / BS 16, SL 16 AdBlue
Urea solution (DEF, ARLA 32) for trucks: nozzle, Safety Break / Break Sleeve and hose assembly
LNG Refuelling
LNG Safety Break SB-LNG VL SB-LNG FL
IBC loading and unloading
MannTek DDC-M 50, FWS 50 PTFE
MannTek Dry Disconnect Couplings:
DDC-V 50-2", DDC-V 50 F, DDC-M 50-2", DDC-M 80-3"
Graphic, components of a ZVA Slimline 2 GR nozzle for vapour recovery
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, vent hose assenbly with 'VC-LNG'
ZVG 2 EURO UL with new scuffguard EA 866 black
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Fuel Grade Identification to EN 16942 for ZVA Nozzles
Type EK FGI - attach with Product Badge EK 145
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
Ship bunkering with LNG
Coupling of DCC male and female part DN 50; left hand side CBC 50 Cryogenic Breakaway Coupling
Elaflex nozzles, hose assemblies and Rubber Expansion Joints for petroleum based products
Hose Reels electrical rewind system yellow
for water
ERV-G
Pump-tank connection; lateral offset
MB 50 TS SS Lockable fi ll pipe coupling
with VK 50 SS
Ship bunkering with LNG
CBC Cryogenic Breakaway Coupling from MannTek and hose assembly for cryogenic media
